Главная Каталог товаров Triumph EPC 2019 Triumph TIGER 800 XCA 855532 > Triumph 2019 Cooling System

Cooling System

Cooling System

Например: T2100775

1

T2100775

Radiator, Flat

2

T2100309

Fan, Cooling

3

T2100081

Cap Assy, Radiator

4

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

3 шт. в узле

5

T3205067

Vis

6

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

7

T3020153

Grommet, 13 x 3 x 10

2 шт. в узле

8

T2101421

Hose, Water Inlet, T-Piece

9

T3706214

Clamp, Constant Tension, Dia 2

4 шт. в узле

10

T3706211

Clamp, Constant Tension, Dia 1

3 шт. в узле

11

T2107200

Hose, Water Inlet, Heat Ex

12

T2105201

Hose, Water Pump, Outlet

13

T3706215

Clamp, Constant Tension, Dia 3

14

T2107014

Pipe, Water, Pump Outlet

15

T3600190

O Ring, 24 x 2.5

16

T3205064

Vis

2 шт. в узле

17

T3600124

O-Ring (21,5x3)

3 шт. в узле

18

T2107012

Pipe, Water Pump Inlet

19

T2100408

Hose, Bypass, Water

20

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

21

T2109005

Hose, Expansion Tank

22

T3700077

Clip, 10.5 Rer Oetiker

23

T2101423

Hose, Water Head to Rad

24

T3706216

Clamp, Constant Tension, Dia 3

25

T2100676

hermostat

26

T2100201

Seal, Thermostat

27

T2100206

Cover, Water Outlet

28

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

29

T2100224

Cover, Water Inlet

30

T2100205

Gasket, Water Inlet

31

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

32

T2108888

Expansion Tank, Coolant

33

T2101015

Cap, Expansion Tank

34

T3450141

Grommet, TPE, Quickfit

35

T2100433

Elbow, Overflow, Quickfit

36

T3202304

Bolt, RHHF, M6 x 20, Slv

2 шт. в узле

37

T2108889

Finisher, Expansion Tank

38

T3330941

Screw, But/Hd, Skt, M5 x 16, S

39

T3351052

Nut, Captive, 4-5.5mm

40

T2100671

Radiator Guard

41

T3700108

Clip, Cable, 14.3 x 10

42

T2108895

Hose, Expansion Tank Overflow

43

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv

44

T3205067

Vis

45

T3010046

Flgd Sleeve, M6 x 9.6 x 10.5

46

T3020033

Damper

47

T2100323

Bracket, Radiator, Lower, Fron

48

T2100168

Bracket, Radiator, Lower, Rear

49

T3205067

Vis

50

T3650200

ADHESIVE TAPE,19MMX50MM

2 шт. в узле

51

T2101551

Clutch Retention Bracket

52

T3700108

Clip, Cable, 14.3 x 10

53

T3350123

Nut, Captive, M5, Non-Secured

2 шт. в узле

54

T3020330

Grommet, Rectangular

2 шт. в узле

55

T3330892

Bolt, RHHF, M5 x 15, S5041

2 шт. в узле

56

T3551178

Washer, M5 x 15 x 1.6

2 шт. в узле

57

A9610046

Coolant, Hybrid Oat, 12 x 1L
