SWING ARM

SWING ARM
1
6100403004433
Swing arm cpl. sm-r sd-r 07
185 735 ₽/шт
2
60004034000
BUCKET F. SHAFT SEAL RING 03
3
0760304073
SHAFT SEAL RING 30X40X7
4
60004032000
INNER RING JR20X25X38,5 03
5
60004031000
NEEDLE BUSH HK2526B 03
6
60004033000
STOP DISK 03
7
63004066100
Guard chain sliding shoe
8
72210079000
BUCKET
9
59009062016
Vis (spec)
10
5461107610030
Ret. clamp f. brake hose black
106 ₽/шт
11
0009050106
Vis
12
61004060000
Guard chain sliding shoe
13
0081050181
SCREW FOR PLASTIC K50X18 T20
14
46104066050
BUSH FOR CHAINSLIDER GUARD 02
15
61004060050
WASHER CHAINGUARD 05
18
60004041000
PLUG SWINGARM 03
19
60004017000
SCREW M14X1,5 L=73MM 03
20
55009086000
PLUG SFL13
21
60004037144
SWINGARM BOLT CPL. 05
22
60004038200
COLLAR NUT M19X1,5 SW=27MM
23
61104020000
QUICK SUPPORT MAIN STAND
24
0912100456
AH SCREW DIN6912-M10X45 10.9
99
60004230010
SWINGARM REP. KIT

Узлы для 990 SUPER DUKE R (9803G8) [EU] KTM (VIN: VBKVD940)
