REAR WHEEL

REAR WHEEL
1
8000H1720
REAR WHEEL
2
8000H1722
REAR RIM
3
8000H1726
Rayon
3
8000H1725
Rayon
4
69N429005
IPPLE, SPOKE
5
8A00H1368
UB, REAR WHEEL
6
800089572
STOP RING 32X47X7 MM
7
8A0026846
BEARING, RADIAL BALL 6005-2NGK
8
800055878
Vis (M6x1,00x11)
9
8000H6189
Entretoise
10
8B0026846
EARING, RADIAL BALL 25X47X16
11
66N021272
Seegerring
12
8000H1548
SHAFT
13
800096938
Entretoise (Outer)
14
Y00093072
Nut
15
8A00A4859
REAR SPROCKET 43T
16
8000H0158
SCREW - L28
17
Y00043928
Nut (Lock)
18
8F00A6261
CHAIN ASSEMBLY
19
8000A6262
CHAIN LINK REGINA
20
8B0082879
GASKET, GUARD INNER TUBE
21
8B00H4977
Disque de frein

Узлы для SMR 511 HUSQVARNA 2012
