Главная Каталог товаров KTM EPC 2016 KTM Offroad KTM 2016 MX KTM 2016 Offroad 250 SX-F FACTORY EDITION (F8175P1) [US] KTM (VIN: VBKSXK43) REAR WHEEL

REAR WHEEL

REAR WHEEL

Например: 2551000124430

1

2551000124430

REAR WHEEL CPL.2,15X19 inch DID 16

2

25010010144

REARHUB CPL.

3

77710011000

BEARING DISTANCE TUBE 121,5MM

4

0625060058

Roulement

5

0472047175

CIRCLIP DIN0472-47X1,75

6

0760324771

Joint

7

77710016000

DISTANCE BUSHING REAR WHEEL

8

79010071205

SPOKE M4,5X205-19 inch 16

9

77109072000

SPOKE NIPPLE M4,5 AL 11

10

2501007000030A

Rim 2,15X19In. Did

48 644 ₽/шт

11

79010060000

BRAKE DISC REAR 220MM 16

12

59009062013

Vis (spec)

13

50310073200

RIM BAND 18'' AND 19''

16

77710015000

DISTANCE RING

19

7771015104804

Rear Sprocket 48-T

6 442 ₽/шт

19

7771015105104

Sprocket 51-Z Nature

6 442 ₽/шт

19

7771015105204

Rear Sprocket 52-T

6 215 ₽/шт

21

0019080266S

Vis (M8x26)

22

06923080003

Nut

23

78910065118

CHAIN 520 GPXV GOLD

23

50310165118

CHAIN 5/8X1/4'' MX

24

78910066000

CONNECTING LINK F. 78910065118

24

50310166000

CONNECTING LINK F. 50310165118

33

78110090200

Tyre locker 2,15"

34

77110090050

NUT FOR WHEEL HOLDER

38

55003135000

PLUG FOR RIM

39

50210086000

COVERING CAP SFL16

40

77710085044

WHEEL SPINDLE CPL. '13

41

77710084000

CHAIN TENSIONER R/S

42

50304040100

screw M10x1.25x50 WS10

43

58414030000

Nut (M10x1,25)

44

61010086000

COLLAR NUT M25X1,5 WS=32 05

97

77710015010

REAR WHEEL REP. KIT

98

SPAA14U51BM1187

Drivetrain set XC 14T/51T

99

00050000979

SPOKE KIT REAR 19"
