Rear Swingarm

Rear Swingarm

Например: T2050475

1

T2050475

Swingarm Spares Assembly

1 шт. в узле

2

T2050446

Spindle, Swingarm

1 шт. в узле

3

T3800014

Roller bearing

1 шт. в узле

4

T3600162

Oil Seal, 32 25 4

3 шт. в узле

5

T2050468

Sleeve, Ground, 25 x 17 x 41

1 шт. в узле

6

T3800227

Bearing, Ball, 30 37 9

2 шт. в узле

7

T3500087

Circlip, Internal, 37 x 1.5

1 шт. в узле

8

T3600307

Seal, 28 37 5

1 шт. в узле

9

T2050774

Spacer, Internal

1 шт. в узле

10

T3800228

Brg, Needle, Solid, 28 37 20

1 шт. в узле

11

T2050469

Adapter, Spindle

1 шт. в узле

12

T3350155

Locknut, Thin, M16

2 шт. в узле

13

T2050535

Finisher, Swingarm Spindle

1 шт. в узле

14

T3010137

Sleeve, Ground, 28 x 17 x 28

1 шт. в узле

15

T2050502

Pin, Pivot, M36, Hdless

1 шт. в узле

16

T2050910

Lock Ring, M36

1 шт. в узле

17

T2050536

Boot, Rubber, Oval

1 шт. в узле

18

T3701050

Band Clamp, 55mm

2 шт. в узле

19

T3701060

Band Clamp, 78mm

1 шт. в узле

20

T2050185

Rubber Boot, Rear

1 шт. в узле

21

T3800199

Bearing, Needle Roller, 20 x 2

2 шт. в узле

22

T2057399

Sleeve, Ground Steel, 90mm

1 шт. в узле

23

T3600178

Seal, 20 x 26 x 4

2 шт. в узле

24

T3450567

Plug, Barrel, 12.8, Black

2 шт. в узле

25

T2050666

Pivot Pin, M30

1 шт. в узле

26

T2500870

Sensor, Swingarm Position

1 шт. в узле

27

T3050341

Screw, Cap/Hd, M5 x 10, Slv

2 шт. в узле

28

T2050253

Droplink, Position Sensor

1 шт. в узле

29

T2050490

Ballstud, Dia 8.0, M6 x 14

2 шт. в узле

30

T3350300

Nut, M6 x 1.0, Slv

1 шт. в узле
