OIL PUMP - FILTER » LUBRICATION SYSTEM

OIL PUMP - FILTER » LUBRICATION SYSTEM
Например: 17420383D
1
17420383D
Pompe à huile
2
066070110
Oil pump cover
3
17410021A
GEAR, OIL PUMP DRIVE
4
066070065
GEAR, PUMP DRIVEN
5
25010021A
OIL PUMP BODY
6
77150678B
pc - Vis
7
68010011B
2 pc - .WOODRUFF KEY 4X4X8
8
77110471A
pc - Vis
9
85310041A
.SPRING WASHER 6 MM
10
77151292B
.SCREW M8X40
11
85310021A
pc - Rondelle (spring)
12
17410011A
PUMP GEAR T58
13
88450361A
pc - Seeger
15
075949280
Dowel pin
16
22032083A
Rondelle
17
78020471A
Vis de vidange d'huile (Magnetic)
18
78710091A
Rondelle
19
066049800
OIL NET FILTER
20
44440039A
Filtre à huile
21
81510281A
BOLT UNION
22
938232037
10 pc - O-Ring
23
77910262A
.SCREW M12X1
24
77910171A
. THREADED PLUG
25
22020176A
pc - Rondelle (ALU)
26
066549360
. NIPPLE
27
78010371A
.THREADED PLUG M14X1.5
28
88440421A
.SPRING RING
29
85250241A
Rondelle
30
81510011A
NIPPLE
31
87510051A
OIL DELIVERY PIPE
32
42020008A
10 pc - Rondelle
33
77910152A
BOLT, OIL HOSE M8X1.00X20
34
74110011A
Collier
35
715021613
SCREW M6X10
36
067049310
BUSH
