Главная Каталог товаров Polaris EPC 1994 Polaris ATV Polaris 1994 300 6X6 (W948730) Polaris 1994 ATV MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010) | MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010)

MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010) | MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010)

MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010) | MAGNETO ASSEMBLY 6x6 300 W948730 (4926792679D010)

Например: 4020129

1

4020129

RESISTOR PLUG CAP

2

3084813

FLYWHEEL W/RING GEAR

3

3081253

SCREW W/WASHER

4

3084817

STATOR #1

5

3082226

SCREW AND WASHER ASSY.(10)

6

3084814

PLATE ASM. (Incl. 3,4,7-14)

6

3084815

PLATE,COIL

7

3081467

Vis

8

3081296

Collier

9

3083909

COUPLER

10

3081260

ASM. SCREW&WASHER

11

3084819

Damper

12

3084816

HARNESS WIRE

13

3084818

SCREW&WASHER ASM.

14

3083422

COIL EXCITING

15

3083923

COIL IGNITION

16

3084820

CDI SYSTEM

17

4011335

SWITCH-MAGNETIC
