LUBRICATING SYSTEM

LUBRICATING SYSTEM
Например: 62638081033
1
62638081033
OIL TANK CPL.
2
58030020100
Bouchon de remplissage d’huile
3
0770191015
O-Ring
4
62638081060
PIPE FITTING
5
59030022100
BLEEDER FLANGE M12X1,5 WS=13
8
58030021100
Vis de vidange d'huile
9
58038022000
Rondelle
10
62538034030
PREFORMED HOSE 9X15 05
11
62638060000
SUCTION PIPE CPL
12
0770090021
O-RING 9X2 VITON
13
0770110021
O-RING 11X2 VITON
14
62638061000
RETURN OIL LINE CPL
16
00050170706
VARIABLE ONE-EAR CLAMP 17,0MM
18
60038017000
OIL SCREEN FINISHED 03
19
60038018000
GASKET FOR OIL FILTER HNBR 03
20
60038024000
PLUG 10MM LC8 03
22
60038037000
RETAINING PLATE 2 LC8 03
23
60038036000
RETAINING PLATE 1 LC8 03
24
0912060163
AH SCREW DIN0912-M 6X16
25
60038083000
SCREW OIL TANK FIXING 03
26
0019050121
COUNTERSUNK SCREW ISA25 M5X12
27
62638084044
OIL SIGHT GLASS CPL.
37
00049160121
CLAMP STD DN16
40
60038010133
PRESSURE PUMP HOUSING CPL. 10
41
60038026000
CONTROL SPRING LC8 3,5 BAR
42
60038128000
CONTROL PISTON
43
50337073000
SHIM
45
60038011000
ROTOR-SET PRESSURE PUMP 03
46
60038002000
OIL PUMP SHAFT 03
47
0402041580
needle roller NRB 4x15.8 G2
48
60038001024
OIL PUMP GEAR 24-T 03
49
0799080000
retaining washer DIN 6799 - 8
50
60038007010
washer 10x16x0.5
51
60038009000
ROTOR-SET 19MM 03
52
60038008000
SUCTION PUMP CASE 03
53
0402040980
NEEDLE ROL.DIN5402 NRB 4X9,8
54
0770133024
O-RING 13,3X2,4 VITON
55
60038016000
OIL SCREEN 03
56
0025060406
Vis
57
0025060256
Vis
59
0770010010
o-ring 10.00x1.00 NBR70
60
60030065100
OIL INJECTION TUBE GEAR 05
61
61338015200
Filtre à huile
62
0025060166
Vis
