FRAME

FRAME

Например: 6260300130004

1

6260300130004

FRAME ''626LA'' ORANGE

2

54403135000

PLASTIC CAP SFL10

3

6250300500033S

Engine support l/s 07

11 963 ₽/шт

4

6250300600033S

Engine support r/s 07

12 760 ₽/шт

5

0035100249

SHCS M10x24 TX45

6

54310086100

SELF LOCKING NUT M10 CU WS=14

7

60003013000

Vis (M10x172)

8

60003014000

ENGINE BRAC. SCREW M10X206 03

9

60004076100

CHAIN SLIDING BLOCK 05

10

0017060206

SCREW F. PLASTIC K60X20AL SW6

11

62603005050

COVER ENGINE SUPPORT LEFT

12

62603006050

COVER ENGINE

13

0019050121

COUNTERSUNK SCREW ISA25 M5X12

14

55530044000

Nut

15

61003088000

PLUG SFL28 05

19

60003044000

BOLT FOR FOOTREST REAR 03

21

0799060003

retaining washer DIN 6799 - 6

22

60003152000

ENGAGE PANEL FOOTREST L/S 03

23

60003052000

ENGAGE PANEL FOOTREST R/S 03

24

60003098000

RUBBER SLEEVE 03

25

58403060000

CHAIN ROLL 12X29X22,5 '98

26

58403060065

BUSH CHAIN ROLL 8X12X23 '98

27

0025080406

Vis

28

36003014000

Rondelle (Lock)

30

6260300220033

Sub Frame Sm Black 2011

82 521 ₽/шт

31

0019100289S

COUNTERSUNK SCREW ISA45 M10X28

32

60003001051

COLLAR BUSHING 10X15X25X4 03

34

6250304800033S

Footrest bracket rear l/s 07

16 086 ₽/шт

35

6250304900033S

Footrest bracket rear r/s 07

13 159 ₽/шт

36

0019080266S

Vis (M8x26)

38

60003050000

FOOTREST CPL. L/S REAR 03

39

60003051000

FOOTREST CPL. R/S REAR 03

46

60103088000

PLUG ZK 8/5 06

50

78003040050

FOOTREST L/S 08

51

78003041050

FOOTREST R/S 08

52

60003040010

FOOTREST RUBBER FRONT L/S 03

53

60003041010

FOOTREST RUBBER FRONT R/S 03

54

60003044010

CLOSING PANEL FRONT L/S R/S 03

55

0985050003

SELF LOCKING NUT DIN0985-M 5

56

54803044000

PIN FOR FOOT PED 51.5X9.8 MM

57

54603041000

FOOTREST SPRING L/S & R/S

58

0125100003

washer DIN 125 A 10.5

59

0094032253

PIN DIN0094-3,2X25 STEEL

60

60003095100

CAGE NUT M8

61

60011038000

CAGE NUT M6 SL K100-1 1,5MM

62

54603048000

RANGE CHANGE METAL NUT M8

63

54603048100

clip nut M6

64

0019100239S

COUNTERSUNK SCREW ISA45 M10X23

65

61003002080

BLIND RIVET NUT M8 HUC/ROF 5 0

97

78003040044

FOOTREST KIT 990 SMR

98

60004076110

CHAIN SLIDING KIT BELOW

99

58403060010

CHAIN ROLL KIT 06-13
