LUBRICATING SYSTEM

LUBRICATING SYSTEM
Например: 77338002100
1
77338002100
OIL PUMP SHAFT
2
77338107100
Pompe à huile
3
77338012000
GASKET PRESSURE PUMP CASE
4
77338207100M01
PRESSURE PUMP PEEK D=9MM
5
77338004100
PUMP COVER 07
6
0912050123
AH SCREW DIN0912-M 5X12
7
0402031580
NEEDLE ROLLER DIN5402 3X15,8
8
77338001100
OIL PUMP GEAR 18-T
9
77338023000
WASHER 10,2X18X1
10
0799080000
retaining washer DIN 6799 - 8
11
77338010100
PRESSURE PUMP CASE
12
0402040980
NEEDLE ROL.DIN5402 NRB 4X9,8
13
77338112000
GASKET PRESSURE PUMP COVER
14
77338013100
PRESSURE PUMP COVER
15
0025060406
Vis
16
77338000150
OILPUMP IDLER GEAR 24-T.
18
77338061050
Rondelle (Lock)
19
77338061000
BEARING BOLT
20
77338022000
OIL INTAKE SNORKEL
21
0770023015
O-RING 23,00X1,50 NBR 70
22
77338016100
OIL SCREEN CPL.
23
0770300020
O-Ring (30x2,0 FPM)
24
77338019100
PLUG SCREW
25
0401100000
BALL D=10 DIN 5401
26
77338026100
COIL SPRING
27
0603142016
CU-SEAL RING 14X20X1,5 LC8 02
28
60038033050
PLUG SCREW M14X1,5 ALU AH
29
76338041010
OIL LINE CONNECTOR
30
07703305178
O-Ring
30
0770275025
O-RING 27,5X2,5 NBR
31
76338050000
OIL LINE CONNECTOR
32
0025060166
Vis
33
0770012021
O-RING 12X2 VITON GREEN
34
76338027000
SWIVEL PRESSURE REGULATOR
35
0603101420
COPPER GASKET 10,2X14X2 MM 01
39
76238000000
Refroidisseur d’huile
40
76338035000
OIL PIPE RIGHT
41
76338034000
OIL PIPE LEFT
42
31008060000
rubber grommet D=8mm open
43
76212090070
INSULATED SCREW JOINT M6
44
0014060203
Vis
45
76338036000
OIL PIPE BELOW
46
0603100141
Rondelle
47
0076431001900
Banjo bolt, type A DIN 7643-3 DN4 M10x1
49
59038041000
OIL FILTER COVER RACING
50
07700390261
O-Ring (39,34x2,62)
52
0025050166
Vis
53
83538005000
Filtre à huile
54
76338043000
OIL FILTER CASE
55
76303004000
SILENTBLOCK 20X10 M6X10
56
50233041000
pc - Rondelle (Lock)
57
0025060086
Vis
58
76338141000
OILFILTER CAP
59
76338037000
ADAPTER ALU METRIC
