FRAME

FRAME
Например: 7630300100090
1
7630300100090
FRAME 450 RALLY 2011
2
76203039000
FOOTREST BRACKET RIGHT 07
3
76203038000
FOOTREST BRACKET LEFT 07
5
0912080303
Vis (M8x30)
6
36003014000
Rondelle (Lock)
7
76304066000
CHAIN SLIDING PART 11
8
51103053051
BUSHING 8,2X10X20
9
0025080356S
Vis
10
76203041250
FOOTREST RIGHT RALLY 07
11
76203040250
FOOTREST LEFT RALLY 07
12
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
13
54603041000
FOOTREST SPRING L/S & R/S
14
0125100003
washer DIN 125 A 10.5
15
0094032253
PIN DIN0094-3,2X25 STEEL
16
76305062000
RUBBER GROMMET 30X20-M8X20
17
54603048000
RANGE CHANGE METAL NUT M8
18
76203005030
RADIATOR STRUT
19
76403034000
FUEL TANK SUPPORT PLATE
20
76303006000
ENGINE SUPPORT RIGHT 11
21
76303005000
ENGINE SUPPORT LEFT 11
22
76203005040
CROSS MEMBER CPL. 08
23
76203005031
RUBBER INSERT
24
76203005050
BUSH ENGINE SUPPORT
26
0025080356
Vis
27
76203001066
JOINT PLATE SEAT 07
28
59009062013
Vis (spec)
29
76203001072
ADAPTER MONOSHOCK ANCHOR BOLT
30
76304266001
BUSHING
31
0912100163
Ah screw din0912-m10x16
32
50233041100
Rondelle (Lock)
33
0025080206
Vis
34
76203018000
ELASTOMER BEARING
35
76203019000
COLLAR BUSH FOR ELAST.BEARING
36
55530044000
Nut
37
0912101503
AH SCREW DIN 912 M10X150 10.9
38
76303001089
BRACKET OILFILTER
39
76303001074
FIXING PLATE VOLT. REGULATOR
40
0025060406
Vis
43
76202095051
SLEEVE FOR CHOKE CABLE
44
76303096000
Sprocket cover
45
71003007000
STEERING HEAD LOCK CPL. ZADI
46
76202095000
CHOKE-CABLE l = 235 07
47
76330047005
SPACER BUSHING CHAIN GUARD
48
76303005041
BUSHING TANK RIGHT
50
58512068100
FIXING SCREW TANK REAR
51
60512063050
NUT F.TANK BRAKET REAR
52
0025080456
Vis
