Главная Каталог товаров Polaris EPC 2000 Polaris ATV Polaris 2000 XPLORER 400 (A00CG38CA) Polaris 2000 ATV GEARCASE - A00CG38CA (4954875487C011) | GEARCASE - A00CG38CA (4954875487C011)

GEARCASE - A00CG38CA (4954875487C011) | GEARCASE - A00CG38CA (4954875487C011)

GEARCASE - A00CG38CA (4954875487C011) | GEARCASE - A00CG38CA (4954875487C011)

Например: 9990000

0

9990000

Suspension, Rear

1

3233525

Vis

2

3233054

Rondelle

3

3233526

DAMPENER CARB.VIBRATION

4

3233448

PLUG

5

3233035

Rondelle

6

3233527

BUSHING PIVOT

7

3233252

Vis

8

3234036

GEARCASE-LH MACH

9

3233529

PIPE KNOCK

10

3233020

Roulement

11

3233558

GEAR 98T HCR.

12

3233544

SHAFT OUTPUT

13

3233545

SPROCKET 16/26T

14

3233546

CHAIN ROLLER

15

3233788

SEAL-TRIPLE LIP

16

3233542

WASHER THRUST

17

3233541

BUSHING GARLOCK

18

3233540

SHAFT PINION 13T

19

3233306

RING RETAINING

20

3233263

COVER-BEARING

21

3233539

Vis

22

3233538

SPROCKET 14/22T

23

3233537

RING RETAINING

24

3233704

SHAFT-INPUT HIGH/LOW/REVERSE

25

3233018

Roulement

26

3233176

Rondelle

27

3233009

BEARING NEEDLE

28

3233666

ENGAGEMENT-DOG,LOW

29

3233019

Roulement

30

3233010

Rondelle

31

3233532

SPROCKET,24T,12-POINT

32

3233029

RING RETAINING

33

3233036

CHAIN SILENT 34P

34

3233535

GEAR 30T 12-POINT

35

3233177

RING RETAINING

36

3233534

BUSHING GARLOCK

37

3233533

DOG ENGAGE 12PT HI/REV

38

3233012

Rondelle

39

3233014

BEARING NEEDLE

40

3233703

SHAFT-REVERSE,31T

41

3233665

GEAR,33T

42

3233706

SHIFT FORK-LOW

43

3233633

FORK SHIFT HIGH/REV

44

3233547

BELLCRANK

45

3233961

NUT-LOCK HEX FLANGE NYLON 5/16

46

3233153

BELLCRANK

47

3233045

RING RETAINING

48

3233040

Rondelle

49

3233548

O-Ring

50

3233549

SHAFT SHIFT

51

3233749

Vis

52

3233636

DECAL-SWITCH

53

3234002

SWITCH-GEAR INDICATION 3 PSTN

54

3234001

SWITCH-GEAR INDICATION 2 PSTN

55

3233037

VENT

56

3233556

COVER SNORKEL

57

3233555

O-Ring

58

3233554

SHIM

59

3233553

GEAR SNORKEL

60

3233552

BUSHING GARLOCK

61

3233324

Rondelle

62

3233711

PLUG OIL FILL

63

3233895

GEARCASE-RH HLR

64

3233043

DEFLECTOR OIL

65

3233747

Rondelle (Lock)

66

3233309

BRACKET INTERLOCK

67

3233032

Spring

68

3233308

PIN INTERLOCK
