Главная Каталог товаров Triumph EPC 2023 Triumph Tiger 1200 GT Pro Triumph 2023 (VIN: SMTTAP22) Gear selector drum

Gear selector drum

Gear selector drum

Например: T1190134

1

T1190134

Selector Fork Shaft

2 шт. в узле

2

T1197911

Fork Selector, Input

1 шт. в узле

3

T1198911

Fork Selector, Output

2 шт. в узле

4

T1199900

Selector Drum

1 шт. в узле

5

T3802210

Bearing, Needle, 22 x 28 x 10

1 шт. в узле

6

T1190286

Bearing, Ball

1 шт. в узле

7

T1191020

Detent Wheel

1 шт. в узле

8

T1190207

Keeper Plate

1 шт. в узле

9

T1194200

Dowel, Detent Arm

1 шт. в узле

10

T1191031

Detent Arm Assembly

1 шт. в узле

10

T1191095

Spares Kit, Detent

1 шт. в узле

11

T3331499

Screw, Pan/Hd, Tx, M6 x 35

1 шт. в узле

12

T3554200

Washer, Hardened, 6.5 x 16 x 1

1 шт. в узле

13

T3050302

Capscrew, Skt/Hd, M6 x 35

1 шт. в узле

14

T3051062

Screw, M6 x 12, Enc, Raw

2 шт. в узле

15

T1191025

Keeper Plate

1 шт. в узле

16

T1198765

Pivot Plate

1 шт. в узле

17

T3000205

Dowel, Solid, 8 x 35

1 шт. в узле

18

T1192522

Spring, Coil, Pivot Plate

1 шт. в узле

19

T3550444

Washer, 15.5 x 25

1 шт. в узле

20

T1191070

Return spring

1 шт. в узле

21

T3550236

Washer, 14 x 20 x 1.6

2 шт. в узле

22

T3502535

Circlip, Din 471, Dia. 14.0

2 шт. в узле

23

T1199920

Selector Mechanism Shaft Assy

1 шт. в узле

24

T3800001

Bearing, Needle, 20x14x12

2 шт. в узле

25

T3600088

Seal, Oil, 14 x 22 x 4.5

1 шт. в узле

26

T3553333

hrust Washer, 12.25 x 28 x 1.2

1 шт. в узле

27

T3500044

E Circlip

1 шт. в узле

28

T1191091

Spring, Linear, Detent

1 шт. в узле

28

T1191095

Spares Kit, Detent

1 шт. в узле
