GEAR CHANGE MECHANISM » UNCLASSIFIED

GEAR CHANGE MECHANISM » UNCLASSIFIED
Например: 79910491A
1
79910491A
2 pc - SPRING, RETURN
2
85210532A
Rondelle
3
77910391A
Vis (M8x21,5)
4
45520181A
GEAR FIXING CLICK ASSEMBLY
5
85211971A
Rondelle (COPPER)
5
050403085
.GASKET 1.5 MM
5
85211111A
.GASKET 0.5 MM
6
53910211A
Swich Neutral light
7
77912033A
.SCREW M16X1.5
8
027291090
pc - .GASKET 16.2X24X2
9
066013143
pc - GEAR SELECTOR SPRING
10
768351134
0 pc - .BALL 11MM
11
180Z0031A
GEAR SELECTOR FORK,1ST/4TH-2ND/3RD
12
180Z0041A
FORK-SHIFT, 5TH&6TH
13
82113881A
FORK PIN
14
85210051A
pc - .THRUST WASHER 1 MM
15
735001542
Seeger
16
88210061A
.NEEDLE RETAINING RING
17
82110701A
.SPECIAL ROLLER
18
18220181A
CAM, GEAR SHIFT
19
066013060
.THRUST WASHER 45.2X49X1.0
20
79912961A
Return spring
21
076592205
.THRUST WASHER 10.5X15X0.2
21
076592205
.THRUST WASHER 10.5X15X0.2
22
88450341B
pc - . SPRING RING
23
74810401A
20 pc - Nut
24
18020261A
CONTROL FORK
25
066013165
.GEARCHANGE LEVER PIN
26
82110011A
GEAR SELECTOR SHAFT
27
79915061A
SPRING, SHIFT RETURN
28
77150678B
pc - Vis
29
85211721A
Rondelle (6x14.2x1.3)
30
77151238C
0 pc - Vis (M8x18)
31
85310021A
pc - Rondelle (spring)
32
88110121A
CENTERING RING
33
82610261A
STOPPER PLATE
34
040029125
.THRUST WASHER 15.5X22X0.2
34
040029126
.THRUST WASHER 15.5X22X0.5
