Главная Каталог товаров Triumph EPC 2018 Triumph TROPHY 1215 SE Triumph 2018 Gear Change Mechanism

Gear Change Mechanism

Gear Change Mechanism
Например: T2088007
1
T2088007
Gearchange Assembly
2
T2088008
Gearchange Pedal Assembly
3
T2080529
Rubber, Gearchange Pedal
2 шт. в узле
5
T2080532
Seal, Gearchange
2 шт. в узле
6
T2081666
Clip, Wire Retention
2 шт. в узле
7
T2088009
Gearchange Rod
8
T3350300
Nut, M6 x 1.0, Slv
9
T3350304
Nut, LH, M6, Slv
10
T2088010
Gearchange Clamp Assembly
12
T3331520
Bolt, Shld, M8 x 1.25, Slv, Enc
13
T3050334
Screw, Cap/Hd, M6 x 20, Slv
14
T1194444
Shaft Assy, Pivot Gearchange
15
T1191207
Spring, Gearchange Return
16
T1191200
Plate, Pivot
17
T1192521
Spring, Coil, Pivot Plate
18
T3551056
Washer, 14.5 x 25 x 1.5, Steel
2 шт. в узле
19
T3502535
Circlip, Din 471, Dia. 14.0
2 шт. в узле
20
T1191189
Abutment Pin, Dowel, Dia 8mm
21
T1192123
Spring, Detent, Torsion
21
T1195432
Spring, Detent, Torsion
22
T1192122
Detent Arm, Assembly
