Cockpit Subframe & Screen

Cockpit Subframe & Screen
Например: T2304114
1
T2304114
Front Subframe
2
T3350111
Nut, Captive, M6
4 шт. в узле
3
T3020030
Grommet, Rubber
2 шт. в узле
4
T3200092
Bolt, RHHF, M8 x 30, Slv, Enc
4 шт. в узле
5
T3350129
Nut, Captive, M5
5 шт. в узле
6
T2304115
Front Subframe, Fabrication
7
T3350109
Captive Nut, M8, Slv
4 шт. в узле
8
T3555033
Washer, 8.4 x 24 x 2
2 шт. в узле
9
T3205457
Bolt, HHF, Lghtd, M8 x 20, Enc
4 шт. в узле
10
T3020059
Grommet, Bodywork
2 шт. в узле
11
T2304994
Screen Adjustment Mechanism
11
T2304944
SCREEN ADJUSTMENT MECHANISM
12
T3200148
Bolt, M6 x 30, Silver
4 шт. в узле
13
T2304116
Screen Support, LH
14
T2304117
Screen, Support, RH
15
T3021180
Rubber Foot, Dia 11.0 x 15.6
2 шт. в узле
16
T2304540
Pivot Pin, 8.1 x 22.5
4 шт. в узле
17
T3750011
Bush, Flanged, 8 x 10 x 4
8 шт. в узле
18
T2304158
Circlip, Ext, 8, Quick Release
4 шт. в узле
19
T3600331
Rubber Washer
6 шт. в узле
20
T2304110
Screen, Standard
20
T2308811
High Touring Screen, Quantum
21
T3550316
Rondelle (plastic)
2 шт. в узле
22
T2304112
Screen Mounting Cover, LH
23
T2304113
Screen Mounting Cover, RH
24
T3331062
Bolt, But/Hd, M5 x 16, Shld, S
6 шт. в узле
25
T2504511
S-Clip
