FUEL TANK

FUEL TANK

Например: 4758A

1

4758A

SCREW, HEX SOCKET

2

4771

SCREW, HEX SOCKET

3

6702

WASHER, PLAIN, TYPE A

4

7531

LOCKNUT.

5

10014

Collier

6

CLIP, vapor valve mounting

7

26556-04

VACUUM HOSE ASSY

7

26588-04

VACUUM HOSE ASSY

8

VENTLINE, tank-to-valve w/ 27250-96A

9

27096-04A

VENT LINE, VALVE TO ATMOSPHERE

10

27250-96B

CONNECTOR, 90 DEG, ELBOW

11

28911-04A

HOSE, VENTLINE VALVE TO CANIST

12

52494-04

MEDALLION, FUEL CAP

13

61100-194

CAP,FUEL,GASKET

14

FUEL CAP, vented w/ 52494-04, 61109-85D

15

FUEL CAP, w/ 61109-85D

16

61348-04

F/TNK, XL SPORT, PRIME

17

62150-85

VAPOR ORIFICE

18

62161-02

NUT, FUEL VALVE

19

62166-02

FUEL FILTER VALVE, SHORT WHITE

20

62169-02A

FUEL VALVE BODY, XL

21

62172-02

5 pc - GASKET, FUEL VALVE

22

62213-04

F/TNK, XL CUSTOM, PRIMED

23

62347-04

FUEL HOSE

24

70903-04

TRIM,BRACKET,LH/FRT,F'TNK

25

70904-04

TRIM, LH, TANK

26

70917-04

TRIM,RH/FRT,F'TANK BRKT

27

70919-04

TRIM,RH/FRT,F'TANK BRKT

28

71276-04A

CONSOLE ASSY, FUEL TANK

29

89579-91

PROTECTIVE CAP

30

89586-04

CAP, THREAD PROTECTOR

31

63501-68B

FUEL HOSE, RUBBER

32

62555-95

SHIELD FUEL HOSE, .605 ID BLK
