CARBURETOR (1 OF 2)

CARBURETOR (1 OF 2)

Например: 3275

1

3275

SCREW, HEX SOCKET HEAD CAP

2

10014

Collier

3

11291

SEAL, MANIFOLD AIR PRESSURE SE

4

26995-86B

Intake manifold Gasket

5

27002-89

SEAL RING, CARB, XL

6

27009-86A

FRONT INTAKE FLANGE MOUNTING

7

27010-86A

REAR INTAKE FLANGE MOUNTING

8

INTAKE MANIFOLD KIT, w/ 38723-99 & 68042-99

9

27090-89

MAIN JET, 1200/883

9

27114-88

MAIN JET, XL1200, CAL

9

27185-90

MAIN JET, FX'S,FL'S, ULTRA

10

27100-88

JET NEEDLE, CARB, XLH883/1200

11

27101-88

JET NEEDLE, HOLDER, XLH883/120

12

27124-89

E-CLIP,CARB

13

27125-89

WASHER,CARB

14

27126-89

LEVER, ACCELERATOR PUMP, XL

15

27127-89

WASHER,CARB

16

27128-89

PIN, CARB, XL

17

27130-90

SCREW,CARB

18

27136-90A

SPRING, CARBURETOR

19

27137-81

WASHER,CARB

20

27146-89

SCREW, ACCEL. PUMP, XL

21

27148-89

WASHER,CARB

22

27156-89

ROD, CARBURETOR, XL

23

27157-89

O-RING, CARBURETOR, XL

24

27158-89

SCREW, DRAIN, CARBURETOR, XL

25

27162-89

CARBURETOR COIL SPRING, XL

26

27171-89

SLOW JET, CAL, XL

27

27256-01

FLOAT CHAMBER ASSY W/ACCEL. PU

27

27777-04

FLOAT BOWL ASSY

28

27260-00

PUMP HOUSING, CARB

29

27261-96

CARBURETOR TOP

30

27262-96

SCREW,TOP,CARB

31

27263-96

COLLAR, CARB

32

27311-76

CARBURETOR BOOT

33

27315-88A

SPRING, ENRICHNER

34

27317-88

SCREW, CARB, XL

35

27320-04

BRACKET, THROTTLE WIRE

36

27360-76

O-RING,CARB

37

27361-76A

DIAPHRAM, ACCELERATOR PUMP, CA

38

27362-76

SPRING,CARB

39

27368-76

CLIP,RUBBER TUBE

40

HOSE, overflow

41

27371-76A

L-JOINT, FUEL INLET, CARB

42

27490-04

CARBURETOR, DOM, 883/C

42

27495-04

CARBURETOR, CALIFORNIA, 883/C

42

27732-04

CARBURETOR, CALIFORNIA, 1200C/

42

27731-04

CARBURETOR, DOM, 1200

43

27575-88A

PIN, CARB, XL, DOM/CA
