Главная Каталог товаров Triumph EPC 2009 Triumph ROCKET III TOURING Triumph 2009 (VIN: SMTC05LR) Front Forks & Yokes

Front Forks & Yokes

Front Forks & Yokes

Например: T2045400

1

T2045400

Fork Leg Assembly, LH

1

T2045441

Fork Leg Assembly, LH

2

T2045405

Fork Leg Assembly, RH

2

T2045443

Fork Leg Assembly, RH

3

T2040169

Cap, Fork

2 шт. в узле

4

T2040081

O Ring, Fork Seal

2 шт. в узле

5

T2045412

Collar, Spring

2 шт. в узле

6

T2045043

Guide spring

2 шт. в узле

7

T2045414

Spring

2 шт. в узле

8

T2045415

Cylinder, Fork

2 шт. в узле

9

T2045416

ube, Fork

2 шт. в узле

10

T2047104

Oil Lock, Fork

2 шт. в узле

11

T2040323

Dust Seal

2 шт. в узле

12

2040079-T0301

Ring snap

2 шт. в узле

13

T2045556

Oil seal

2 шт. в узле

14

2040077-T0301

Rondelle

2 шт. в узле

15

T2045559

Sliding bush

2 шт. в узле

16

T2045442

ube Outer, LH

16

T2045401

ube, Outer, LH

17

T2045406

ube, Outer, RH

17

T2045444

ube Outer, RH

18

T2045404

Clip, Abrasion

2 шт. в узле

19

T2045045

Washer, Sealing B

2 шт. в узле

20

T2045046

Capscrew, Oil Lock

2 шт. в узле

21

T3050133

Capscrew

2 шт. в узле

22

T2045425

Yoke Assy, Lower

22

T2045399

Lower Yoke Assy

23

T2047044

Capscrew, M10 x 30, S/S

2 шт. в узле

24

T3800031

Bearing, 30x55x17, Taper Roll

25

T3203050

Bolt, Domed, S/S, M6 x 50

4 шт. в узле

26

T3800032

Bearing, 24x47x15, Taper Roll

27

T2046552

Cover, Headstock Bearing

28

T2041265

Adjuster Nut, Lower

29

T2140210

Adjuster Nut, Upper

30

T2045407

Shroud, Lower Fork

2 шт. в узле

31

T2045427

Shroud, Upper, Fork, LH

32

T2045428

Shroud, Upper, Fork, RH

33

T2045433

Grommet, Fork Shroud Top

2 шт. в узле

34

T2045431

Grommet, Fork Shroud, Bottom

2 шт. в узле

35

T2045430

Cover, Screen, Lower

2 шт. в узле

36

T3010037

Flanged Sleeve, M8 x 12.8 x 11

2 шт. в узле

37

T3550223

Washer, Curve Spring, M12

2 шт. в узле

38

T2045439

Cap, Stainless

2 шт. в узле

39

T2045445

Bush, Stainless

2 шт. в узле

40

T3550277

Washer, M8

2 шт. в узле

41

T3331022

Screw, M8 x 30, S/S

2 шт. в узле

42

T2045432

Shroud, Fork, Infill

43

T3021100

Grommet, Dia 13 x 1.8

4 шт. в узле

44

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

2 шт. в узле

45

T3205067

Vis

2 шт. в узле

46

T3450060

Cap

47

T3020602

Grommet, Castellated

2 шт. в узле

48

T2700332

Reflector, Amber, Oval

2 шт. в узле

49

T3551820

Locating Washer, 25.5x38x2, Sl
