Electrical Equipment

Electrical Equipment

Например: T2502701

1

T2502701

Main Harness

1

T2501096

Main Harness, ABS

1

T2501117

Kit, Main Harness & Gear Senso

2

T2501305

Fuse, Mini, 5A

2 шт. в узле

3

T2501310

Fuse, Mini, 10A

2 шт. в узле

4

T2501315

Fuse, Mini, 15A

3 шт. в узле

5

T2501320

Fuse, Mini, 20A

2 шт. в узле

6

T2500805

Fuse, 30A

7

T3700136

Clip, Connector Dual

8

T2502406

Bracket, Relays

9

T2501330

Fuse, Mini, 30A

10

T2501335

Fusebox Lid

11

T2501300

ool, Mini Fuse Replacement

12

T2500259

Relay, Grommet

4 шт. в узле

13

T2501160

Clip, Harness, Firtree

14

T3450255

Plug, Retainer, Plastic

2 шт. в узле

15

T2501705

Relay, Changeover

16

T2502109

Relay, EFI

3 шт. в узле

17

T2502450

La batterie

17

T2502376

Battery Multipack (10)

18

T2501740

Battery Strap

19

T3700091

Clip cable

3 шт. в узле

20

T3700222

Clip, Cable, Dia 25mm, BLK

2 шт. в узле

21

T3700909

Clip, Cable, M10 Fir Tree

22

T2505600

Shield, Plastic

23

T2502430

Bracket, Battery Box

24

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv

6 шт. в узле

25

T2502405

Switch, Fall Detection

26

T3330390

Screw, H/Hd, M4 x 25, Slv, Enc

2 шт. в узле

27

T3555021

WASHER, 4.3X16.0X1.0

2 шт. в узле

28

T2500103

Horn Assy, Low-Tone

29

T3205868

Bolt, HHF, Lghtd, M8 x 33, Slv

29

T3205653

Bolt, HHF, Lghtd, M8 x 30, Slv

30

T2500253

Mat, Battery

31

T2502417

Retainer, Engine Harness

32

T3700222

Clip, Cable, Dia 25mm, BLK

2 шт. в узле

33

T2040811

win Clip, Brake Hose

34

T3330891

Bolt, RHHF, M5 x 0.8 x 12, S50

3 шт. в узле

35

T2506502

Bracket, Assembly, ECM

35

T2506500

Bracket, ECM Assy

36

T2506503

Retaining Strap, ECM

36

T2506501

Retaining Strap, Ecu

37

T3330891

Bolt, RHHF, M5 x 0.8 x 12, S50

3 шт. в узле

38

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

39

T2502416

Bracket, Alarm, Main Harness

40

T3701010

Clip, Cable, Dia 21mm

41

T2502401

Subharness, Battery, Negative

42

T3205156

Bolt, HHF, Lghtd, M8 x 18, Slv

43

T2502402

Subharness, Battery Positive

44

T2502404

Subharness, Throttle Bodies

45

T2040884

Clip, Twin, Speedo, Brake

3 шт. в узле

46

T2500497

Cable Guide (Wires & Hoses)

47

T2500495

Plate, Wire Retainer

48

T3205061

Bolt, HHF, Lghtd, M6 X 10, Slv

2 шт. в узле

48

T3203201

Bolt, HHF, Lghtd, M6 x 10, SS

2 шт. в узле

49

T2502407

Flylead, Starter

50

T2502418

Bracket, ABS Fusebox

51

T2709026

Subharness, Relay, Lightbar

51

T2709036

Subharness, Relay, Lightbar

52

T2502109

Relay, EFI

3 шт. в узле

53

T2709030

Spacer, Horn
