Главная Каталог товаров KTM EPC 2012 KTM Street KTM 2012 Travel KTM 2012 Street 990 ADVENTURE WHITE ABS 11 (9860L6) [AU, GB] KTM FRAME

FRAME

FRAME

Например: 6010300120004

1

6010300120004

Frame 601Ka Orange

225 269 ₽/шт

2

54603048000

RANGE CHANGE METAL NUT M8

3

54603048100

clip nut M6

4

0025080406

Vis

5

58403060000

CHAIN ROLL 12X29X22,5 '98

6

58403060065

BUSH CHAIN ROLL 8X12X23 '98

7

36003014000

Rondelle (Lock)

8

60004076100

CHAIN SLIDING BLOCK 05

9

0017060206

SCREW F. PLASTIC K60X20AL SW6

10

58303070100

BUMP RUBBER M8X25MM

11

0934080003

Nut

13

55530044000

Nut

14

60003013000

Vis (M10x172)

15

60003014000

ENGINE BRAC. SCREW M10X206 03

16

6000300500001S

ENGINE SUPPORT LEFT 07

17

6000300600001S

Engine Support Right

16 639 ₽/шт

18

60003098000

RUBBER SLEEVE 03

19

0035100249

SHCS M10x24 TX45

20

54310086100

SELF LOCKING NUT M10 CU WS=14

21

6000300200033

Sub frame black 09

91 754 ₽/шт

22

0019100239S

COUNTERSUNK SCREW ISA45 M10X23

23

60003001051

COLLAR BUSHING 10X15X25X4 03

24

62503085000

COVER FRAME L/S FRONT 05

25

62503086000

COVER FRAME R/S FRONT 05

26

0081050181

SCREW FOR PLASTIC K50X18 T20

27

60003087000

SPLASH PROTECTOR FRAME 05

28

60103088000

PLUG ZK 8/5 06

29

0019100289S

COUNTERSUNK SCREW ISA45 M10X28

30

6000309100092

Underride protection 10

11 738 ₽/шт

31

60003092100

UNDERRIDE PROTECTION LEFT 06

32

60003093100

UNDERRIDE PROTECTION RIGHT 06

33

6000309400092

Lower tank holder front 10

16 967 ₽/шт

34

60003097000

COLLAR SCREW M8 03

35

60003095000

CAGE NUT M6 SL 4MM 03

36

0024060156

Vis

37

60003096000

VIBRATION DAMPER 03

38

0025080166

Vis

39

60003040133

FOOTPEG LS+RS CPL.

40

78003040050

FOOTREST L/S 08

41

78003041050

FOOTREST R/S 08

42

54803044000

PIN FOR FOOT PED 51.5X9.8 MM

43

54603041000

FOOTREST SPRING L/S & R/S

44

0125100003

washer DIN 125 A 10.5

45

0094032253

PIN DIN0094-3,2X25 STEEL

46

60003040010

FOOTREST RUBBER FRONT L/S 03

47

60003041010

FOOTREST RUBBER FRONT R/S 03

48

60003044010

CLOSING PANEL FRONT L/S R/S 03

49

0985050003

SELF LOCKING NUT DIN0985-M 5

50

6000304800033S

Footrest bracket rear l/s 09

14 940 ₽/шт

51

6000304900033S

Footrest bracket rear r/s 09

15 286 ₽/шт

52

0019080266S

Vis (M8x26)

53

54403135000

PLASTIC CAP SFL10

54

60003050000

FOOTREST CPL. L/S REAR 03

55

60003051000

FOOTREST CPL. R/S REAR 03

56

60003044000

BOLT FOR FOOTREST REAR 03

57

60003152000

ENGAGE PANEL FOOTREST L/S 03

58

60003052000

ENGAGE PANEL FOOTREST R/S 03

59

0799060003

retaining washer DIN 6799 - 6

98

60004076110

CHAIN SLIDING KIT BELOW

99

58403060010

CHAIN ROLL KIT 06-13
