FRAME

FRAME
Например: 49003350000
0
49003350000
FOOTREST REAR R/S CPL.
0
5460314000019
FOOTREST R/S '93
0
58303103000
*FOOT REST BRACKET REAR R/S 93
1
54603101500
* FRAME 250/300 SX USA '94
1
54603401500
FRAME SX,MXC,EXC,EGS '94
2
54603002100
* SUBFRAME ALU MX,EXC,EGS '94
2
54603202100
% subframe steel '94
2
54603402000
% subframe steel '94
3
5830300300030
FOOTRESTBRACKET REAR L/S BLACK
11 349 ₽/шт
4
0025080166
Vis
5
54603045100
* ENGINE BRACE 250/300/360 '94
7
54603055000
ENGINE MOUNTING 250/300 '90
8
71003007000
STEERING HEAD LOCK CPL. ZADI
9
49003250000
FOOTREST REAR L/S CPL.
10
0934100003
HEXAGON NUT DIN0934-M10
11
0025060406
Vis
11
0912060404
AH SCREW DIN0912-M 6X40 A2
12
54603013000
engine brac.scr. M10x105 WS13
13
0019080206S
Vis (Flat M8x20)
14
0019080266S
Vis (M8x26)
15
56530079000S
Hh Collar Screw M8X44 Ws13
184 ₽/шт
16
54606004000
PLUG 37MM
20
52303053100
CHAIN ROLL D=35MM 125-380 '99
21
0625006087
GROOVED BALL BEAR. 608 2RS C3
22
0015080353
Vis
22
0912080353
AH SCREW DIN0912-M 8X35
23
74003021000
BUSHING 8.2 X 12 X 6
24
50203053000
CHAIN ROLL D=30MM
25
54310086000
Null
26
54310086100
SELF LOCKING NUT M10 CU WS=14
32
50203028000
Window pane 8,4x14x1mm
33
36003014000
Rondelle (Lock)
39
0933080353
HH SCREW DIN933 M8x35
40
5460304000019
Foot rest l/s '93
4 502 ₽/шт
41
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
42
54603041000
FOOTREST SPRING L/S & R/S
43
0125100003
washer DIN 125 A 10.5
44
0094032253
PIN DIN0094-3,2X25 STEEL
50
54607061000
SPROCKET COVER
51
54630061000
CHAIN SLIDING PLATE 14 T/15 T
52
54603048100
clip nut M6
53
54613038150
BUSHING 6,5X8X11
54
0025060206
Vis
54
0912060203
AH SCREW DIN0912-M 6X20
55
0912050203
AH SCREW DIN0912-M 5X20
55
0933050203
HH SCREW DIN933 M5x20
56
54603073000
COLLAR BUSHING 5 X 10 X 6 ALU
57
44011076200
CABLE TIE 200/3,6MM BLACK
