F-13 FRONT FORK

F-13 FRONT FORK
Например: 51400-KEY-901
1
51400-KEY-901
FORK ASSY., R. FR. (###)
2
51401-KFG-003
SPRING, FR. CUSHION
3
51410-KFG-003
ork inner tube
20 230 ₽/шт
4
51412-GC4-731
RING, BACK UP
535 ₽/шт
5
51420-KEY-901
CASE COMP., R. FR. BOTTOM
6
51425-KL8-901
Fork dust seal
1 368 ₽/шт
7
51432-GE4-003
PIECE OIL LOCK
1 085 ₽/шт
8
51437-KFG-003
RING, PISTON
550 ₽/шт
9
51440-KFG-003
PIPESEAT
3 486 ₽/шт
10
51449-KFG-003
CAP, FORK PIPE
456 ₽/шт
11
51454-KFG-003
SEAT, SPRING UPPER
1 054 ₽/шт
12
51456-KEY-901
RINGSTOPPER 29.8
13
51490-KL8-900
Fork oil seal and dust seal kit for one tube
2 273 ₽/шт
14
51500-KEY-901
FORK ASSY., L. FR. (###)
15
51520-KEY-901
CASE COMPL FR BO
16
90116-383-721
Vis
429 ₽/шт
17
90544-283-000
Rondelle (Spec. 8mm)
236 ₽/шт
18
90601-369-000
RING, OIL SEAL STOP
322 ₽/шт
19
91356-KFG-003
O-Ring
244 ₽/шт
20
51412-KFG-003
SPRING, REBOUND
