E-17-10 TRANSMISSION

E-17-10 TRANSMISSION
Например: 11211-K40-F00
1
11211-K40-F00
TUBE, MISSION BREATHER
2
21200-K40-F00
CASE COMP., MISSION
3
21395-KZR-600
GASKET, TRANSMISSION CASE
833 ₽/шт
4
23411-K40-F30
DRIVESHAFT (17T)
5
23421-K40-F30
COUNTERSHAFT (14T)
6
23422-K40-F30
GEAR, COUNTER (53T)
7
23430-K40-F30
GEAR COMP., FINAL (45T)
8
90495-MN5-000
Rondelle
225 ₽/шт
9
91005-KZR-601
oulement
1 085 ₽/шт
10
91006-KAB-004
Roulement
1 590 ₽/шт
11
91006-KZR-601
oulement
975 ₽/шт
12
91204-K35-J01
oint
1 069 ₽/шт
13
94301-10120
DOWEL PIN, 10X12
121 ₽/шт
14
95002-50000
Collier
39 ₽/шт
15
95701-080-4500
Bolt
91 ₽/шт
16
95701-080-5500
Bolt, flange, 8x55
91 ₽/шт
