CYLINDER HEAD

CYLINDER HEAD
Например: 7503602014452
1
7503602014452
Cylinder Head Cpl
72 822 ₽/шт
2
75030036000
Joint culasse
3
0474050100
GROOVED PIN DIN1474 5X10
4
0835080256
Stud bolt (8x25 10.9)
5
60036026101
Valve (EX)
6
60036025101
VALVE GIUDE INTAKE
7
60036078050
SHIM 10,2X19X1,5MM 05
8
75036079000
CYLINDERHEAD SCREW M10X168WS14
9
75035047000
Water temperature switch
10
0770100020
o-ring 10.00x2.00 silicone
11
49030090000
Dowel 9,8 x 7 x 10
12
59030296000
SCREW PLUG
14
75036053000
VALVE COVER GASKET 07
15
75036052000
VALVE COVER 07
16
75036052050
BREATHER COVER 07
18
0025050106
HH collar screw M5x10 TX30
19
0770150151
O-RING 15,00X1,50 VITON
20
75036055000
VALVE COVER SCREW 05
21
75036052010
decoupling element
22
75036044000
INTAKE BOOT 07
23
75036047000
HOSE CLAMP GEMI 70MM
24
0603061001
CU-SEAL RING DIN7603-6X10X1
25
0025060086
Vis
26
0025060256
Vis
28
60005026000
reed valve
29
76530088000
PRE.HOSE OIL SEPARATOR FOAM 08
30
00049200121
CLAMP STD DN20
31
00049210121
CLAMP 21X12 STD-DES
