CRANKSHAFT, PISTON

CRANKSHAFT, PISTON
Например: 59030118000
1
59030118000
Vilebrequin
2
59030015044
CON.ROD REP.SET 250/520 RAC.00
4
50330082000
CYL.ROLLER BEAR.NJ206 ET2XCS46
5
59030055000
DRIVE GEAR 32-T F.BALANC.SHAFT
6
56030081000
Rondelle (30,5x45x0,10)
6
56030081100
THRUST WASHER 30,7X47X0,15
6
56030081200
Rondelle (30,5x45x0,30)
7
0888030050
WOODRUFF KEY DIN6888-3X5X13
8
0984060162
AH SCREW DIN7984-M 6X16
9
0760304772
Joint (SHAFT SEAL RING)
13
83032022031
PRIMARY GEAR 31T CPL.
15
59030029100
Nut (M20X1,5 WS=27 LEFT)
16
6946005
Woodruff key (5x6,5)
17
0760142460
radial shaft seal 14x24x6 B
18
0471250120
CIRCLIP DIN0471-25X1,2
20
49030021000
COLLAR NUT M12X1 R/S
21
0137120000
SPRING WASHER DIN0137-B12
33
59030033000
PISTON PIN BOLT 20X15,8/12X50
34
59030074000
CIRCLIP C20X1,5
50
59030007000I
Piston i 95mm cpl. forged 2000
55 718 ₽/шт
50
59030007000II
Piston i 95mm cpl. forged 2000
55 718 ₽/шт
51
58030631000
OIL SCRAPER RING 95MM
52
59030032000
RECTANGULAR RING 95/87,2X1,25
