CARBURETOR

CARBURETOR
Например: 83031001000
1
83031001000
CARBURETOR FCR-MX 3925H,TPS 08
5
57331027044
CARBURETOR COVER WITH GASKET
12
57331046100
THROTTLE SHAFT CPL. 06
14
83031046050
COIL SPRING THROTTLE SHAFT ATV
16
76231035051
LINK ARM THROTTLE VALVE CPL.07
19
57331035100
THROTTLE VALVE CPL. FCRMX 2007
20
59031035050
BUSHING THROTTLE VALVE
21
57331035153
GASKET PLATE THROTTLE VALVE 04
22
59031035052
GASKET WASHER THROTTLE VALVE
23
57331034500
JET NEEDLE KEIHIN OBEKT
23
57331034400
JET NEEDLE KEIHIN OBEKS
23
57331034300
JET NEEDLE KEIHIN OBEKR
23
57331034200
JET NEEDLE KEIHIN OBEKQ
23
57331034100
JET NEEDLE KEIHIN OBEKP
24
59031029000
BAR CLIP
25
57331032000
NEEDLE SET SCREW CPL.
26
59031121000
NEEDLE JET FCR-MX
27
54531623165
MAIN JET 165 KEIHIN
27
54531623168
MAIN JET 168 KEIHIN
27
54531623170
MAIN JET 170 KEIHIN
27
54531623172
MAIN JET 172 KEIHIN
27
54531623175
MAIN JET 175 KEIHIN
27
54531623178
MAIN JET 178 KEIHIN
27
54531623180
MAIN JET 180 KEIHIN
28
54531607038
IDLE JET 38 KEIHIN
28
54531607040
IDLE JET 40 KEIHIN
28
54531607042
IDLE JET 42 KEIHIN
28
54531607045
IDLE JET 45 KEIHIN
29
59031051085
STARTER JET 85
30
57331107100
IDLE AIR JET 100 KEIHIN
32
59031017100
ADJUST SCREW CPL. FCR-MX
35
57331085000
BUFFER PLATE
39
57331009000
FLOAT CPL.
40
57331008000
ARM PIN FLOAT
41
57331075100
HOT-STARTER VALVE CPL. 06
42
54631220000
FLOAT NEEDLE
43
54531621000
Collier
46
76231155000
DRAIN SCREW . O-RING
47
57331060000
COVER ACCELERATOR PUMP
48
57331057100
DIAPHRAGM ACCELERATOR PUMP
49
78031011000
FLOAT CHAMBER CPL. 08
50
54631085000
JET POWER JET CLOSED KEIHIN
53
59031059000
COIL SPRING
55
77031048000
STARTER VALVE SHORT CPL.
56
57331098000
BREATH.HOSE FCR-MX KEIHIN CPL.
60
83031094000
SCREW FOR COVER
61
54531699000
PLUG M 18X1
64
57331062000
INTERMEDIATE LEVER CPL.
65
57331056000
LINK LEVER
66
57331059000
SPRING LINK LEVER
67
57331159000
SPRING INTERMEDIATE LEVER
68
83031038000
COVER, GASKET, HOSE
69
57331087000
WASHER LINK LEVER
70
57331084000
E-CLIP
71
83031038001
GASKET FOR CARBURETOR COVER
72
57331061000
ROD ACCELERATOR PUMP
79
58431082100
YDNAC-CLAMP 10173 (16MM) '98
83
59031013044
HOSE CONNECTOR CPL.
85
0910100003
PLUG DIN0910-M 10X1
86
0603100141
Rondelle
87
59031040300
HOSE CONNECTOR KEIHIN
88
83031050000
ENGINE BREATHER TUBE
90
57331025000
STOP SCREW CPL. FCR-MX
96
59031077200
TPS-SENSOR FCRMX 190MM 2006
99
57331099000
GASKET SET FCR-MX KEIHIN (FCR-MX KEIHIN)
