CARBURETOR | CARBURETOR, LOWER - A06MH50FB (4999200099920009D08)

CARBURETOR | CARBURETOR, LOWER - A06MH50FB (4999200099920009D08)

Например: 3130543

1

3130543

GUIDE CABLE

2

3130931

THROTTLE SHAFT ASM.

3

3130932

RING

4

3130927

Spring

5

3130933

Vis

6

3130926

Rondelle

7

3130925

CASE

8

3130515

SEAL

9

3130928

O-Ring

10

3131359

VALVE-NEEDLE 1.5

11

3130624

JET PILOT #40

12

3131475

Vis

13

3130907

VALVE THROTTLE 120

14

3130921

FLOAT ASM.

15

3130917

Gasket - float chamber

16

3130923

FLOAT BODY ASM.

17

3130935

Vis

18

3130919

RING

19

3130570

MAIN JET #152.5

20

3130239

O-Ring

21

3130321

PLUG DRAIN

22

3131242

CLIP

23

3131295

ASM-CABLE ADJUSTER

24

3131296

Rondelle

25

3130010

Spring

26

3130924

Vis

27

3130930

Couvrir

28

3130929

O-Ring
