CARBURETOR - A02CD32AA/AB/AC/FB (4970147014D11) | CARBURETOR - A02CD32AA/AB/AC/FB (4970147014D11)

CARBURETOR - A02CD32AA/AB/AC/FB (4970147014D11) | CARBURETOR - A02CD32AA/AB/AC/FB (4970147014D11)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3130730

JET NEEDLE (J8-5F14)

4

3130752

RING

5

3130732

DIAPHRAGM ASM.

6

3131130

NEEDLE-JET

7

3130541

Vis

8

3130540

WASHER SPRING

9

3131128

JET BLOCK,ASM.

10

3130014

WASHER

11

3130567

MAIN JET #145

12

3130515

SEAL

13

LR--

CALIPER, BRAKE, RH

14

3130518

E-RING

15

3130519

CAP

16

3130361

PIN FLOAT

17

3130594

PLATE

18

3130532

Gasket - float chamber

19

3130520

Vis

20

3130590

FLOATBODY ASM.

21

3130521

Vis

22

3130529

FLOAT ASM.

23

3130591

Vis

24

3131360

VALVE-NEEDLE 1.5(PUSH IN)

25

3130533

O-Ring

26

3131132

JET PILOT(#50)

27

3130522

O-Ring

28

3130523

Rondelle

29

3130525

Spring

30

3131131

ADJUSTER

31

3130546

SCREW ADJ

32

3130545

RING

33

3130544

Spring

34

3131126

VALVE-THROTTLE(120) (120)

35

3130589

Spring

36

3130514

RING

37

3130501

Vis

38

3130513

SHAFT ASM THROTTLE

39

3130543

GUIDE CABLE

40

3130535

Vis

41

3130511

Couvrir

42

3130512

O-Ring

43

3130199

HOLDER GUIDE

44

3130538

Spring

45

3130539

PLUNGER ASM.

46

3131133

JET AIR(#175)

47

3131383

ASM-CARBURETOR

48

3084205

ASM. SCREW & WASHER

49

3131129

Spring

50

3131127

COVER,ASM.

51

3130924

Vis
