Главная Каталог товаров Polaris EPC 2000 Polaris ATV Polaris 2000 SPORTSMAN 335 (A00CH33AE) Polaris 2000 ATV CARBURETOR - A00CH33AC (4959905990D007) | CARBURETOR - A00CH33AC (4959905990D007)

CARBURETOR - A00CH33AC (4959905990D007) | CARBURETOR - A00CH33AC (4959905990D007)

CARBURETOR - A00CH33AC (4959905990D007) | CARBURETOR - A00CH33AC (4959905990D007)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3130541

Vis

4

3130540

WASHER SPRING

5

3130924

Vis

6

3130503

ASM. COVER

7

3130505

Spring

8

3084205

ASM. SCREW & WASHER

9

3130904

CARBURETOR (Incl. 1-13,18-52)

10

3130625

JET AIR PILOT #160

11

3130539

PLUNGER ASM.

12

3130538

Spring

13

3130199

HOLDER GUIDE

14

3130512

O-Ring

15

3130511

Couvrir

16

3130535

Vis

17

3130543

GUIDE CABLE

18

3130513

SHAFT ASM THROTTLE

19

3130501

Vis

20

3130514

RING

21

3130589

Spring

22

3130515

SEAL

23

3130502

VALVE THROTTLE 100

24

3130544

Spring

25

3130545

RING

26

3130546

SCREW ADJ

27

3130624

JET PILOT #40

28

3130522

O-Ring

29

3130523

Rondelle

30

3130525

Spring

31

3130524

ADJUSTER

32

3130905

PLUG

33

3130529

FLOAT ASM.

34

3130521

Vis

35

3130590

FLOATBODY ASM.

36

3130520

Vis

37

3130532

Gasket - float chamber

38

3130591

Vis

39

3130594

PLATE

40

3131360

VALVE-NEEDLE 1.5(PUSH IN)

41

3130533

O-Ring

42

3130361

PIN FLOAT

43

3130519

CAP

44

3130518

E-RING

45

LR--

CALIPER, BRAKE, RH

46

3130569

MAIN JET #150

47

3130014

WASHER

48

3130504

JETBLOCK ASM.

49

3130731

NEEDLE JET (P-9)

50

3130732

DIAPHRAGM ASM.

51

3130752

RING

52

3130730

JET NEEDLE (J8-5F14)
