Главная Каталог товаров Triumph EPC 2022 Triumph Scrambler 1200 XE Triumph 2022 Airbox

Airbox

Airbox

Например: T2203552

1

T2203552

Kit, Airbox Assembly

1 шт. в узле

1

T2203551

Airbox Assembly

1 шт. в узле

2

T2201434

Drain Tube, Sealed

1 шт. в узле

3

T3700089

Hose Clip, Dia 12.5

1 шт. в узле

4

T2201958

Hose, Crankcase Breather

1 шт. в узле

5

T3700050

Hose Clip, Dia 19.5-22.0 x 8mm

2 шт. в узле

6

T2201936

Intake Duct, Airbox

1 шт. в узле

7

T2201993

Intake Duct, Airbox

1 шт. в узле

8

T2201816

Air Filter

1 шт. в узле

9

T2201887

Seal, Filter Face

1 шт. в узле

10

T2201824

Cassette, Air Filter

1 шт. в узле

11

T3330319

Screw, S/Tap, 5 x 20

4 шт. в узле

12

T3701080

Band Clamp, 72mm

1 шт. в узле

13

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

2 шт. в узле

14

T3331234

Screw, Torx, P/H, M6 x 20, Slv

2 шт. в узле

15

T2201896

Mount, Intake Finisher, LH

1 шт. в узле

16

T2202842

Mount, Intake Finisher, RH

1 шт. в узле

17

T3331075

Bolt, But/Hd, M5 x 14, Slv

4 шт. в узле

18

T3350161

Nut, Captive, M5

2 шт. в узле

19

T3020131

Grommet, 9 x 2 x 6

4 шт. в узле

20

T2201740

Finisher, Intake, LH

1 шт. в узле

21

T2201817

Finisher, Intake, RH

1 шт. в узле

22

T3332656

Screw, Button, M5 x 0.8 x 12,

2 шт. в узле

23

T2203213

Wire Guide, SAI

1 шт. в узле

24

T2203371

Connector, SAI Hose

1 шт. в узле

25

T3331414

Screw, S/Tap, Torx, 5 x 16

2 шт. в узле

26

T3606360

O Ring, 14 x 17.6 x 1.6

1 шт. в узле
