69 - REAR WHEEL (SPOKE WHEELS)

69 - REAR WHEEL (SPOKE WHEELS)

Например: 64110-11001

1

64110-11001

Hub, rear wheel

2

64210-11002

Panel

3

55420-30000

SPRING

221 ₽/шт

4

64440-38A00

Cam ,brake

5

09160-15048

Шайба

102 ₽/шт

6

64611-34000

Drum, sprocket mounting

7

64651-11002

ABSORBER,RR HUB SHOCK

1 564 ₽/шт

8

64711-47000

Axle, rear

9

09180-17039

Spacer, rh (17.5*28*51.8)

10

64733-34000

Retainer, sprocket drum

11

09180-17042

Spacer 17x30.5x

12

09160-17050

Шайба

1 250 ₽/шт

13

09141-16001

Nut

14

04111-4030A

Шпонка

85 ₽/шт

15

64410-34110-XNA

16

64730-11000

Entretoise

17

08143-63037

Подшипник

1 308 ₽/шт

18

08143-62037

BEARING

1 122 ₽/шт

19

09262-25003

Подшипник B1 25X52X15

1 360 ₽/шт

20

64451-44001

Lever,rr.br.cam

21

09118-06086

Болт 6X25

1 680 ₽/шт

22

09285-30003

Seal,oil(30.5X52X8)

1 623 ₽/шт

23

09280-15003

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

204 ₽/шт

24

64511-47001

Sprocket, rear (nt:50)

25

09105-10002

Bolt 8x33.5

26

08310-00107

Гайка

85 ₽/шт

27

09169-10006

Шайба

268 ₽/шт

28

61410-47200

Adjuster,chain

29

09104-08034

BOLT

1 840 ₽/шт

30

08310-00087

Гайка 8MM

81 ₽/шт

31

61433-3100V

SUPPORTER,CHAIN ADJUSTER

32

01550-08507

БОЛТ

2 070 ₽/шт

33

65100-47036

Tire (3.75h18)

34

65200-49015

INNER TUBE 400X18

35

55261-26F10

PROTECTOR,INNER TUBE

486 ₽/шт

35

65261-47620

Protector

36

65311-15021

Rim,rr wheel

37

65300-31831

Spoke set,rr.

38

55411-26G00

Балансир колеса

399 ₽/шт

39

55413-41F00

BALANCER,WHEEL(30G)

469 ₽/шт
