Главная Каталог товаров SUZUKI EPC 350 cm³ - 699 cm³ SUZUKI GS 550 SUZUKI GS550 T SUZUKI 21 - SPEEDOMETER - TACHOMETER

21 - SPEEDOMETER - TACHOMETER

21 - SPEEDOMETER - TACHOMETER

Например: 34110-47130

1

34110-47130

Speedometer (kilo & mile scale)

2

34980-45020

KNOB

305 ₽/шт

3

34210-47110

Tachometer (x1000rpm)

4

34173-45621

Socket

5

34150-45100

Case,meter

6

34951-47020

Bracket

7

34961-45021

Plate,meter und

8

34956-45020

Cushion (a)

9

34955-45020

Cushion (b)

10

08322-0105B

Шайба

81 ₽/шт

11

08313-1005A

Гайка

1 090 ₽/шт

12

03142-04259

Болт

82 ₽/шт

13

36450-47751

14

36452-45100

.case

15

36454-45100

COVER,LWR

602 ₽/шт

16

03511-03146

Болт

1 020 ₽/шт

17

09471-12071

BULB(14V1.12W)

3 440 ₽/шт

18

36457-45100

Vis

19

03211-0412A

Болт

1 060 ₽/шт

20

09471-12001-LCP

Bulb 6v/1,7w

21

36382-45100

Case, pilot

22

09111-08031

Vis

23

34956-31001

CUSHION,METER BRACKET

501 ₽/шт

24

08322-0110B

Шайба

85 ₽/шт

25

09160-08135

Шайба

113 ₽/шт

26

08321-01087

Пластина замка

81 ₽/шт

27

08310-00087

Гайка 8MM

81 ₽/шт

28

34910-45231

CABLE ASSY,SPEEDOMETER

2 229 ₽/шт

29

34938-45100

CLAMP,SPEEDOMETER CABLE

254 ₽/шт

30

08322-0106A

Шайба

81 ₽/шт

31

01550-0616B

БОЛТ

81 ₽/шт

32

34940-47034

Cable Assy,tachometer

3 995 ₽/шт
