61 - REAR SWINGING ARM (MODEL L/N/R)

61 - REAR SWINGING ARM (MODEL L/N/R)

Например: 61000-48711-13L

1

61000-48711-13L

Swinging arm assy, rear (silver)

1

61100-48710

Swinging arm, rear

2

61261-05301

Втулка

1 139 ₽/шт

4

61251-05300

SPACER,RR SWGARM PIVOT

1 208 ₽/шт

5

09286-20001

SEAL,OIL(20X27X5)

179 ₽/шт

6

08211-14341

Шайба

1 720 ₽/шт

7

61262-45002

CVR,RR SWGARM DUST SEAL(OD:40)

544 ₽/шт

8

08322-01147

Шайба

85 ₽/шт

9

08319-2114A

Гайка

2 390 ₽/шт

10

61211-05302

SHAFT,RR SWINGINGARM PIVOT

1 462 ₽/шт

11

61273-05201

KETTINGGELEIDER

12

61341-48504

Направляющая chain

1 785 ₽/шт

13

01580-0816A

Болт

97 ₽/шт

16

64311-48700-13L

TORQUELINK,RR

1 279 ₽/шт

16

64311-48700

Torque link, rear

17

09111-08015

BOLT(8X22)

1 840 ₽/шт

18

09111-08013

BOLT(8X26.5)

178 ₽/шт

19

08321-01087

Пластина замка

81 ₽/шт

20

08322-01087

Шайба

81 ₽/шт

21

09140-08008

ШАЙБА

97 ₽/шт

22

04111-2020A

Штифт

81 ₽/шт

23

61311-01A03

Корпус натяжения

3 825 ₽/шт

24

01550-0610B

Болт

85 ₽/шт

25

09169-06026

Пластина замка

119 ₽/шт
