18B - SPEEDOMETER (MODEL R P09)

18B - SPEEDOMETER (MODEL R P09)

Например: 34120-03D10

1

34120-03D10

СП

20 723 ₽/шт

2

34220-487A0

ТАХОМЕТР

15 836 ₽/шт

3

02112-0310A

Болт

1 060 ₽/шт

4

09162-03001

Шайба блокирующая

900 ₽/шт

5

08322-0103B

Шайба

1 370 ₽/шт

6

34150-487A0

HOOD,METER

8 172 ₽/шт

7

34124-49910

KNOB,TRIP METER

817 ₽/шт

8

34996-49910

SEAL,TRIP KNOB

301 ₽/шт

9

34111-01A00

CASE,METER

5 474 ₽/шт

10

03511-03146

Болт

1 020 ₽/шт

11

34170-487A0

Socket, meter

12

09471-12028

Лампочка

210 ₽/шт

13

09471-12077

BULB(12V1.7W,T10,WB121)

1 990 ₽/шт

14

34950-01A00

METER BRACKET

15

34955-28010

CUSHION

301 ₽/шт

16

09160-05048

WASHER,5.5X14X1.2

81 ₽/шт

17

03111-0412A

Болт

1 060 ₽/шт

18

02112-1612B

Болт

1 520 ₽/шт

19

34162-48780

Bracket, speedometer

20

09320-09010

САЙЛЕНТБЛОК

114 ₽/шт

21

09180-06121

SPACER(6.4X9.2X12)

1 330 ₽/шт

22

09160-06088

ШАЙБА

97 ₽/шт

23

09116-06150

БОЛТ

136 ₽/шт

24

01560-0616A

Болт

1 330 ₽/шт

25

08310-0006B

Гайка

81 ₽/шт

26

34910-13A02

Cable Assy,speedometer

7 038 ₽/шт

27

02112-0516B

Болт

1 090 ₽/шт

28

34938-01A00

CLAMP,SPEEDOMETER CABLE

653 ₽/шт

29

02112-0525A

Болт

85 ₽/шт

30

08310-0005B

Гайка

1 370 ₽/шт

31

09407-18402

Струбцина (L:165)

211 ₽/шт

31

09407-22404

CLAMP

248 ₽/шт

32

34940-48711

CABLE ASSY,TACHOMETER

7 194 ₽/шт

33

34997-48701

GUIDE,TACHOMETER CABLE

375 ₽/шт

33

58621-38300

GUIDE,CLUTCH CABLE

387 ₽/шт

34

02112-7612A

Vis
