49 - REAR WHEEL (MODEL K5)

49 - REAR WHEEL (MODEL K5)

Например: 64150-45F00-YGD

1

64150-45F00-YGD

Wheel, rear (mt1.85x18)

2

64210-45FA0-000

Panel, rear brake anchor

3

54400-45820-000

Shoe set, brake

4

55421-45F10

SPRING,BRAKE SHOE

187 ₽/шт

5

54441-45FA0-000

CAM,RR BRAKE

1 322 ₽/шт

6

09280-14011

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ ПОМПЫ МАСЛЯНОЙ, РЕЗИНА !

226 ₽/шт

7

09160-14055

Шайба

1 450 ₽/шт

8

64451-45FA0-000

LEVER,RR BRAKE CAM

1 200 ₽/шт

9

01550-0635B

Болт

112 ₽/шт

10

08316-10068-000

Гайка

1 330 ₽/шт

11

64711-05320-000

Axle, rear

12

09180-15042-000

Кольцо/шайба

459 ₽/шт

13

08319-3114A

Гайка

646 ₽/шт

14

09180-15002-000

SPACER(15.2X23X33)

459 ₽/шт

15

08144-63027

BEARING(15×42×13)

1 396 ₽/шт

16

08143-62027

ПОДШИПНИК (15×35×11)

937 ₽/шт

17

09180-15011

SPACER(15.3X21.7X63)

4 070 ₽/шт

18

09285-28004

OIL SEAL

1 088 ₽/шт

19

64610-05301

DRUM,RR SPROCKET MOUNTING

5 161 ₽/шт

20

64651-38300

ABSORBER,RR HUB SHOCK

1 595 ₽/шт

21

64733-05301-000

RETAINER,RR SPROCKET DRUM

1 024 ₽/шт

22

09262-20069-000

ПОДШИПНИК(20X47X14)

1 224 ₽/шт

23

61410-36002

ADJUSTER,CHAIN

653 ₽/шт

24

09104-08034

BOLT

1 840 ₽/шт

25

08310-00087

Гайка 8MM

81 ₽/шт

26

64511-05310-000

Sprocket, rear (nt:43)

27

09119-08043

BOLT

1 250 ₽/шт

28

09169-08012

Шайба

1 250 ₽/шт

29

08310-0008B

Гайка

85 ₽/шт

30

65100-45F51-000

TIRE,RR

23 069 ₽/шт

31

43130-45F00-000

VALVE ASSY,WHEEL RIM

931 ₽/шт

32

43300-45F10-000

Rod assy, rear brake

33

08322-0106B

Шайба

81 ₽/шт

34

09440-09004

SPRING

129 ₽/шт

35

09209-11002

Рукоятка кулочка тормоза

178 ₽/шт

36

09150-06010-000

Гайка

194 ₽/шт

37

09200-06013

PIN(L:13.5)

194 ₽/шт

38

04111-2015A

Штифт

81 ₽/шт

39

08322-0106B

Шайба

81 ₽/шт
