39 - FRONT FORK

39 - FRONT FORK
Например: 51100-35E00-E91
1
51100-35E00-E91
Fork assy,front
2
51210-35E00
Stem,steering
3
51110-35E00
Tube,inner
4
51132-35E00
Bracket,axle rh
5
51142-35E00
Bracket,axle lh
6
51173-35E00
Seal, dust
7
51135-35E00
Case, seal
8
51152-35E00
Guide, pipe
9
51118-C35E0-0J000
Seeger
10
51171-35E00
Spring
11
51292-35E00
Rubber,stopper
12
51296-10E00
Rondelle
13
07130-0820B
Болт
2 030 ₽/шт
14
51177-35E00
Spring
15
51622-16B00
RACE,STEERING OUTER LWR
817 ₽/шт
16
06111-05004
Шарик стальной
82 ₽/шт
17
51612-16B00
RACE,STEERING INNER LWR
931 ₽/шт
18
51611-16A00-A05
Race,steering i
19
06111-05004
Шарик стальной
82 ₽/шт
20
51621-16A01
RACE,STEERING OUTER UPR
719 ₽/шт
21
09166-26001
ШАЙБА ФОРСУНКИ
980 ₽/шт
22
51631-29C00
NUT,STEERING STEM
457 ₽/шт
