38B - REAR SWINGING ARM (MODEL M/R E22)

38B - REAR SWINGING ARM (MODEL M/R E22)
Например: 61000-13730-13L
1
61000-13730-13L
Rr.swingingarm
2
61261-13700
BUSHING,RR SWGARM PIVOT
962 ₽/шт
3
09283-20031
SEAL,OIL(20X27X5)
339 ₽/шт
4
61251-13700
Spacer,rr
5
61211-1370V
Shaft,rr swgarm
7
08319-2114A
Гайка
2 390 ₽/шт
8
61273-13610
Buffer,chain to
9
61310-13690
Case comp,chain
10
09116-06096
BOLT(6X10)
1 370 ₽/шт
12
61341-13710
Guide,chain
14
61391-13610
Guard, foot (black)
15
09116-06096
BOLT(6X10)
1 370 ₽/шт
16
64311-48700-13L
TORQUELINK,RR
1 279 ₽/шт
17
09111-08013
BOLT(8X26.5)
178 ₽/шт
18
09111-08015
BOLT(8X22)
1 840 ₽/шт
20
09140-08008
ШАЙБА
97 ₽/шт
21
04111-2020A
Штифт
81 ₽/шт
