19 - TRANSMISSION (GSX-R400RL/RM/RN/RP/RR)

19 - TRANSMISSION (GSX-R400RL/RM/RN/RP/RR)

Например: 24120-32C00

1

24120-32C00

ounter shaft

2

24121-30B02

Shaft,counter

3

24221-30B01

Gear,2nd drive,

4

24231-32C02

GEAR,3RD & 4TH DRIVE(NT:16/16)

9 775 ₽/шт

5

24251-32C01

Gear,5th drive

6

09301-22003

Втулка

13 570 ₽/шт

7

08331-31229

Зажимы

153 ₽/шт

8

24260-32C00

Gear,6th drive

9

09181-25167

Шайба

194 ₽/шт

10

09285-17003

Сальник

489 ₽/шт

11

09267-25013

BEARING(25X52X20.6)

4 361 ₽/шт

12

09263-17044

Bearing

13

09390-58001

ПОЛУКОЛЬЦО GV 2.0

1 720 ₽/шт

14

04221-07129

PIN

1 060 ₽/шт

15

24131-33C00

Shaft,drive

16

24310-33C00

GEAR,1ST DRIVEN(NT:37)

9 071 ₽/шт

17

09181-20223

SHIM(20X32X1)

1 720 ₽/шт

18

24321-30B00

GEAR,2ND DRIVEN

8 602 ₽/шт

19

09301-25002

Втулка

8 990 ₽/шт

20

24331-30B00

GEAR,3RD DRIVEN

8 602 ₽/шт

21

24332-30B00

SPACER,3RD DRIVEN GEAR

2 502 ₽/шт

22

09167-25022

Шайба

3 400 ₽/шт

23

24341-30B01

GEAR,4TH DRIVEN

24

09380-25003

КЛИПС

291 ₽/шт

25

24351-32C01

GEAR,5TH DRIVEN(NT:30)

8 289 ₽/шт

26

24361-32C02

Gear,6th driven

27

09262-22028

Подшипник

4 590 ₽/шт

28

09263-20040

ПОДШИПНИК ШАРИКОВЫЙ

4 505 ₽/шт

29

04221-07129

PIN

1 060 ₽/шт

30

09283-30044

SEAL,OIL(30X56X6)

2 100 ₽/шт

31

09390-56001

Кольцо стопорное

2 030 ₽/шт

32

27511-32C00

SPROCKET,ENGINE

3 695 ₽/шт

33

09180-22046

SPACER,22X30X25.4

34

09181-22167

SHIM,22X30X1

194 ₽/шт

35

08331-31229

Зажимы

153 ₽/шт

36

27600-20A21-110

Chain assy, drive (rk525sm0x110le)
