11 - CARBURETOR (FRONT)

11 - CARBURETOR (FRONT)

Например: 13210-39A30

0

13210-39A30

Carburator

0

13210-39A20

Carburetor assy, front

1

02112-0306B

Болт

940 ₽/шт

2

09162-03001

Шайба блокирующая

900 ₽/шт

3

13387-47010

RING

323 ₽/шт

4

13394-40D20

E RING

282 ₽/шт

5

13382-44030

Шайба

4 110 ₽/шт

6

13388-44030

Пружина

1 143 ₽/шт

7

13383-38A30

Жиклер

2 125 ₽/шт

7

13383-39A00

.needle, jet (5d32-3)

8

09494-00588

Jet,needle

9

13382-03110

Шайба

178 ₽/шт

10

13605-05A10

Болт

559 ₽/шт

11

02112-0410A

Болт

740 ₽/шт

12

13689-38A00

Пружина

606 ₽/шт

13

09352-50005-600

ШЛАНГ

436 ₽/шт

14

13573-38A01

.spring

15

13681-04011

CAP

835 ₽/шт

16

13278-47091

O Ring

210 ₽/шт

17

13418-38A00

HOLDER,GUIDE

821 ₽/шт

18

13411-01400

Плунжер

782 ₽/шт

19

13417-08210

Пружина

204 ₽/шт

20

09492-65005

Ось жиклера

1 309 ₽/шт

20

09492-77002

.jet, pilot air (77.5)

21

09492-32004

Jet,pilot

21

09492-25007

Жиклерпроводник #

888 ₽/шт

22

13268-47070

Пружина

272 ₽/шт

23

13295-29901

O-Ring, Pilot Air Screw

210 ₽/шт

24

13291-29900

Шайба

162 ₽/шт

25

13279-47070

Винт топливный

884 ₽/шт

26

13502-38A00

COVER,DIAPHRAGM

2 502 ₽/шт

27

13500-05A10

DIAPHRAGM,CARBURETOR

15 647 ₽/шт

28

13503-05A10

Пружина

864 ₽/шт

29

13389-37400

PLATE

368 ₽/шт

30

13604-44080

Болт

235 ₽/шт

31

02122-0410B

Винт

1 370 ₽/шт

32

13551-38A00

.valve, throttle

33

13251-38A00

Уплотнитель поплавковой камеры

1 211 ₽/шт

34

13385-05A11

HOLDER,MAIN JET

1 024 ₽/шт

35

09491-97004

Жиклер главный (97.5)

1 322 ₽/шт

35

09491-20019

Жиклер главный

1 001 ₽/шт

36

13617-44080

E RING

231 ₽/шт

37

13557-47070

GASKET,THROTTLE SHAFT

301 ₽/шт

38

13556-05A11

Seal,throttle Shaft

238 ₽/шт

39

13247-02340

Заглушка дренажная

258 ₽/шт

40

09404-06039

Clamp(L:65)

194 ₽/шт

41

13480-05A10

.diaphragm assy

42

13481-45C10

Пружина

375 ₽/шт

43

13484-38A00

COVER

1 521 ₽/шт

44

13601-04148

Болт

172 ₽/шт

45

08310-00047

Гайка

81 ₽/шт

46

02112-0430B

Болт

85 ₽/шт

47

13554-45C20

LEVER ASSY

2 796 ₽/шт

48

13376-19F00

Фильтр-сеточка

581 ₽/шт

49

13374-35C00

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

275 ₽/шт

50

13370-01401

Клапан

4 653 ₽/шт

51

13602-05A10

Болт

238 ₽/шт

52

13250-05A10

Поплавок

2 424 ₽/шт

53

13254-20010

Поплавок

178 ₽/шт

54

02112-0510B

Болт

85 ₽/шт

55

13574-01400

.ring

56

09168-05010

Прокладка

980 ₽/шт

57

13605-73000-000

Винт топливный

817 ₽/шт

58

13550-38A00

.shaft assy, throttle

59

13415-38300

E RING

106 ₽/шт

60

13671-38A00

CLIP

759 ₽/шт

61

09352-60104-600

Hose(6X10X600)

1 292 ₽/шт

62

13683-38A21

Шланг топливный

5 161 ₽/шт

63

13641-38A01

CABLE,IDLE SYNCRO

3 060 ₽/шт
