11 - CARBURETOR

11 - CARBURETOR
Например: 13200-45410
0
13200-45410
Carburettor
1
13201-45410
.carburetor, no.1
2
13202-45410
.carburetor, no.2
3
13203-45410
.carburetor, no.3
4
13204-45410
.carburetor, no.4
5
13500-45111
Diaphragm
6
13394-31210
CLIP,NEEDLE
238 ₽/шт
7
13387-44030
RING
323 ₽/шт
8
13389-44030
Держатель направляющей
868 ₽/шт
9
13503-44080
Spring
10
13581-44030
E RING
489 ₽/шт
11
13383-45410
Jet,needle
12
13557-49200
GASKET
254 ₽/шт
13
13578-47070
CAP
364 ₽/шт
14
08310-00087
Гайка 8MM
81 ₽/шт
15
13606-47070
WASHER,THROTTLE SHAFT
16
13573-47070
..spring
17
13550-47070
..shaft
18
02112-05167
Болт
81 ₽/шт
19
13550-45400
..shaft
20
13563-47070
..pin
21
13573-45110
..spring
22
13553-47070
..lever
23
13555-47070
..lever
24
13573-47080
..spring
25
13550-47090
..shaft
26
13651-51011
Seal
231 ₽/шт
27
13617-44080
E RING
231 ₽/шт
28
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
29
13607-47070
Гайка
170 ₽/шт
30
13605-47070
Болт
407 ₽/шт
31
13605-45110
..screw
32
13604-44080
Болт
235 ₽/шт
33
13551-47090
..valve, throttle (135)
34
13258-44080
O ring
35
13251-44081-H17
GASKET,FLOAT CHAMBER
958 ₽/шт
36
13382-44030
Шайба
4 110 ₽/шт
37
13388-44030
Пружина
1 143 ₽/шт
38
09492-42007
Jet,pilot
39
13357-44080
PLUG,NEEDLE JET
318 ₽/шт
40
09494-00278
Jet,needle
41
13382-03110
Шайба
178 ₽/шт
42
09491-22015
JET,MAIN(112.5)
790 ₽/шт
43
13247-44080
Болт
669 ₽/шт
44
13246-44080
Прокладка
231 ₽/шт
45
13250-44080
Поплавок
2 307 ₽/шт
46
02112-0406B
Болт
81 ₽/шт
47
13373-39110
Плата клапана
422 ₽/шт
48
13254-92311
PIN,FLOAT
162 ₽/шт
49
13370-44500
Запорная игла поплавковой камеры
3 655 ₽/шт
50
13374-35C00
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
275 ₽/шт
51
13376-19F00
Фильтр-сеточка
581 ₽/шт
52
02112-05127
Болт
81 ₽/шт
53
13268-44010
..spring
54
13575-47070
..pin
55
13627-45110
..bracket
56
13271-93011
Пружина
204 ₽/шт
57
13267-47070
Screw
58
13276-31210
..bush
59
13627-44090
..bracket
60
13421-47070
..plate
61
01500-0510B
Болт
85 ₽/шт
62
08321-0105A
Пластина замка
81 ₽/шт
63
13394-40D20
E RING
282 ₽/шт
64
13523-98010
SPRING SEAT
65
13422-47070
LEVER ASSY
974 ₽/шт
66
13624-45110
..bracket
67
13425-45110
..rod
68
09493-30003
Жиклерпроводник воздуха
1 552 ₽/шт
69
02112-05167
Болт
81 ₽/шт
70
08321-0105A
Пластина замка
81 ₽/шт
71
13550-45410
..shaft
72
13574-45110
..ring
73
13574-45120
Ring
74
13422-44080
Lever,starter p
75
13605-47070
Болт
407 ₽/шт
76
13410-45400
.shaft
77
13628-45400
.plate
78
02142-0512A
Болт
85 ₽/шт
79
09355-45857-600
Шланг
1 433 ₽/шт
80
13685-45400
.nipple
81
09352-60104-600
Hose(6X10X600)
1 292 ₽/шт
82
13685-45110
Nipple,carburet
83
02112-06127
Болт
81 ₽/шт
83
02122-06127
Болт
85 ₽/шт
84
13685-49210
Ниппель
1 376 ₽/шт
85
13619-49200
.clip
86
13615-49200
WASHER
109 ₽/шт
87
02112-3616A
Болт
1 210 ₽/шт
87
02112-0616A
Болт
81 ₽/шт
