WIRING HARNESS, MAIN - XR1200/X (2 OF 2)

WIRING HARNESS, MAIN - XR1200/X (2 OF 2)
Например: 70225-10
0
70225-10
MAIN HARNESS,XR1200
45
72260-04
HOUSING, 1 WAY FEMAIL
46
72272-07
TERMINAL, SOCKET #14-16 AWG
47
72289-04
TERMINAL, FEMALE, 10-12 AWG
48
72290-94
TERMINAL, .25 OF, INSULATED
49
72291-94
TERMINAL, 56 SERIES, 14-16GA
50
72295-94
HOUSING, .187 TERM
51
72312-04
HOUSING 3 WAY SOCKET
52
72330-95
Fusible (15A)
53
72378-04
CAP, ONE WAY, RED
54
72405-98BK
PUSH-ON WIRE ASSY, RIGHT ANGLE
55
72414-07BK
HOUSING, 6-WAY SOCKET, BLACK
56
72430-00
FUSE MOUNTING BLOCK, TYPE 0
57
72434-00
TERMINAL, JR. POWER-TIMER, 16-
58
72441-04
TERMINAL
59
72445-99TN
FEMALE TERMINAL, .156
60
72469-07GY
HOUSING, 8-WAY SOCKET, GRAY
61
72473-07
SEAL PIN (PLUG)
62
72487-07BK
HOUSING, 12-WAY SOCKET, BLACK
63
72512-07BK
HOUSING, 3-WAY SOCKET, BLACK
64
72516-01
CAP, SIREN CONNECTOR
65
72519-09BK
DUSTCAP, JET SENSOR
66
72543-07BK
HOUSING, 3-WAY FEMALE, BLACK
67
72544-07
SECONDARY LOCK, 3-WAY FEMALE
68
72545-08
RESISTOR ASY, FUEL SENDER
69
72592-10
TERMINAL,SOCKET,#18AWG
70
72611-07
TERMINAL, SOCKET #16-20 AWG/GO
71
73104-96BK
TAB HOUSING, 4-POSITION
72
73106-96BK
TAB HOUSING, 6-POSITION, SINGL
73
73156-96BK
RECEPTACLE, HSG, 6-POSITION SI
74
73190-96
TAB TERMINAL, 20-16 GA
75
73191-96
RECEPTACLE, CONTACT, 20-16 GA
76
73213-07
RETAINER, XMAS TREE CLIP
77
73228-10
COVER ASY,FUSEBLOCK,W/GRAPHICS
78
73301-04
HOUSING, 2 WAY FEMALE
79
73302-04
COVER, FUSE BLOCK
80
73303-04
SECONDARY LOCK, 2-WAY FEMALE
81
73304-04
TERMINAL, .31 FEMALE
82
73305-04
WIRE SEAL #10 BLUE
83
74112-98BK
SOCKET HOUSING, 2-WAY, BLACK
84
74120-08
DC LEAD ASY
85
74152-98
SOCKET LOCK, 2-WAY
86
74191-98
SOCKET, TERMINAL
