WIRING HARNESS

WIRING HARNESS

Например: 60711075033

1

60711075033

Main wiring harness complete

2

60711085100

Engine harness

3

58211058050

BRACKET RUBBER F.STARTRELAY 07

4

60311076000

REAR WIRING HARNESS

5

60311053050

BATTERIE HOUSING

6

60341031050

ECU RUBBER BRACKET

7

61341031300

STEUERGERÄT EFI

8

60311057050

BRACKET ELECTRIC

9

60416031100

ELECTRONIC CONTROL UNIT SAFE

10

58211058000

Relais - démarreur

11

0024060136

Vis

12

60342090100

inertial sensor

13

62142041000

DAMP. COMPONENT ABS MODUL

14

69008021160

Vis (spec)

15

60711048000

Connector support front

16

60411078050

Wiring harness

17

0738060201

FLAT HEAD SCREW ISO7380 M6X20

18

76508043050

COLLAR BUSHING

19

60711033050

Rubber band

20

60711060033

Direct current horn complete

21

58011109140

FUSE 40 A

21

58011109130

FUSE 30 A

21

58011109125

FUSE 25 A

21

58011109115

Fusible (15A)

21

58011109110

FUSE 10 A 2000

22

60316029000

RUBBER EDS-CONTROL UNIT

23

0902060083

Vis

27

60311059050

BATTERIE CABLE

30

60711033000

Control unit MCU 3.0

31

69011168000

Antenna keyless

32

60708019010

Support

33

0081050181

SCREW FOR PLASTIC K50X18 T20

34

60312032000

RECEIVER AIR PRESSURE SENSOR

35

0081050121

EJOT PT screw K50x12

36

0902060083

Vis

37

60311047000

CABLE CHANNEL R/S

39

60311049300

Plug board rear

40

60311034000

Régulateur de tension

41

0025060206

Vis

42

60342090040

BRACKET SLOPING POSITIONS SENS

43

60011053000

La batterie

44

60308017000

BATTERIE COVER

45

61041085050

RUBBER SUPP. PRESSURE SENS. 05

46

60311040100

BRACKET PRESSURE SENSOR

48

0023060123

COLLAR SCREW M6X12 TX

49

60007020040

PLASTIC WASHER 03

50

0025050126

Vis

51

54603048200

RANGE CHANGE METAL NUT M5

52

60711087050

rubber cover fuse holder

53

61111018100

TEMPERATURE SENSOR

54

44011076140

CABLE TIE 140/2,5MM BLACK

54

44011076200

CABLE TIE 200/3,6MM BLACK

54

44011076305

CABLE TIE 300/4,8MM BLACK

55

60011093045

RUBBER CABLE TIE 45MM 03

55

60011093060

RUBBER CABLE TIE 60MM 03

55

60011093075

RUBBER CABLE TIE 75MM 03

60

60711057050

Retaining bracket

61

61111057000

RELAY CM1A-R-12V-H80 07

64

60416063000

ACCLERATION SENSOR

65

60411015000

WIRING HARNESS MONOSHOCK SAFE

66

0025060166

Vis

67

60416062000

WHEEL TRAVEL SENSOR

68

60716065000

Retaining bracket

69

60311046000

CABLE CHANNEL L/S

70

0081045121

SCREW FOR PLASTIC K45X12 T20

74

60416061000

MAGNET HOLDER

75

58605083014

Vis (M5x14)

76

0025050166

Vis

78

60311097000

GROUND CABLE
