VORDERRADGABEL

VORDERRADGABEL
1
4TD-F3100-03
ront fork assy
2
4TD-F3153-00
Seeger
3
4TD-F3154-00
PLUG, INNER TUBE
4
4TD-F3112-00
Rondelle
5
4TD-F3394-00
Vis
6
4TD-F3136-00
UBE, OUTER (RIGHT)
7
4TD-F3126-00
UBE, OUTER (LEFT)
8
4TD-F3183-00
Seeger
9
4TD-F3147-00
O-Ring
10
4TD-F3111-00
Vis
11
4TD-F3144-00
ork dust seal
12
4TD-F3156-00
CLIP, OIL SEAL
13
4TD-F3145-00
Joint
14
4TD-F3141-00
SPRING, FRONT FORK
15
4CU-F3165-00
Rondelle
16
4TD-F3181-00
Vis
17
4TD-F3110-00
INNER TUBE COMP.1
18
5BR-F3340-02
UNDER BRACKET COMP.
20
4SB-F3411-02
RACE BALL 1
21
4SB-F3414-00
RACE, BALL 4
22
4SB-F3412-00
RACE, BALL 2
23
4SB-F3812-00
PLANE BEARING, STEERING
24
4SB-F3427-01
Rondelle
25
90179-25802
Mère

Узлы для CW50RS BW'S NEXT GENERATION (4VA5) 1997 YAMAHA BWS 50 CW 50
