Transmission

Transmission

Например: T1183380

1

T1183380

Gearbox Assy, Input, 6 Speed

2

T1186900

Gearbox Assy, Output, 6 Speed

2

T1183405

Gearbox Assy, Output, 6 Speed

3

T1187001

Input Shaft, Gearbox, 6 Speed

4

T1183406

Output Shaft, Gearbox, 6 Speed

5

T3800555

Bearing, Ball, 25 x 62 x 17

6

T1187005

Input Gear, 5th, 27T

7

T1187004

Input Gear, 3rd/4th, 20T/25T

8

T1187002

Input Gear, 2nd, 18T

9

T1180501

hrust Washer, 28 x 34 x 1.5

10

T3500091

Circlip, 28mm Shaft

11

T1187805

Plain Bush, Input, 5th

12

T3502206

Circlip, Ext, 22 x 1.2

13

T1187006

Input Gear, 6th, 29T

14

T1187008

Bush, Input, 6th, Splined

15

T1183391

Output Gear, 2nd, 45T

16

T1183393

Output Gear, 5th, 35T

17

T1183394

Output Gear, 4th, 37T

18

T1183395

Output Gear, 3rd, 37T

19

T1183397

Output Gear, 6th, 34T

20

T1183396

Output Gear, 1st, 49T

21

T1187042

Spacer, Sprocket, Width 28.4

22

T3800101

Needle bearing

23

T1183777

hrust Washer, 35.5 x 43 x 1.5

2 шт. в узле

24

T3502102

Circlip, ID 32.2

2 шт. в узле

25

T1183398

Plain Bush, Output, 3rd

2 шт. в узле

26

T1183555

hrust Washer, 30.5 x 40 x 1.5

27

T1183399

Plain Bush, Output, 2nd

28

T1187606

hrust Washer

29

T3800555

Bearing, Ball, 25 x 62 x 17

30

T3800189

Snap Ring

31

T3802206

Bearing, Cyl Roll 22, 1 x 40 x

32

T1182222

Restrictor Washer, Gearbox

33

T1180156

Sleeve Assy, Needle bearing

34

T3500201

Circlip, EXT, 23.5 x 1.2

35

T3800159

Bearing, Needle, K25 x 32 x 16

36

T3555016

hrust Washer, 25 x 35 x 1.0

37

T3600113

Seal, Oil 35 x 62 x 5

38

T1189300

Sprocket, Front, 17T, 525

39

T1186601

ab Washer, Sprocket

40

T1180175

Nut, Gearbox Sprocket

41

T3051063

Screw, Cap/HD, M6 x 16, Enc, R

42

T1189876

Bearing Retainer Plate
