Transmission

Transmission
Например: T1270004
1
T1270004
Drive Unit, Front Bevel Box
2
T1181285
Seal, Oil, 25 x 42 x 7
3
T1181287
O Ring, ID 90 x Dia 2.5
4
T3331180
Screw, But/Hd, Skt, M8 x 25
2 шт. в узле
5
T1181282
Cover, Side, Front Bevel Box
6
T3000118
Dowel, Dia 4.0 x 10.0
2 шт. в узле
7
T1181294
Gasket, Side Cover, Front Beve
8
T3331182
Bolt, HHF, M6 x 25, S/S
6 шт. в узле
9
T1181291
O Ring, ID 5.1 x Dia 1.6
10
T3800001
Bearing, Needle, 20x14x12
11
T1181143
Input Shaft Assembly
12
T3500201
Circlip, EXT, 23.5 x 1.2
13
T3555016
hrust Washer, 25 x 35 x 1.0
2 шт. в узле
14
T1180411
Gear, 2nd, Output, 37T
15
T1180051
Washer,Thrust, 41 OD x 1.5
16
T3500270
Circlip, 32mm Shaft
3 шт. в узле
17
T1182214
Gear, Output, 6th, 28T
18
T1180292
Washer, Thrust, Output
2 шт. в узле
19
T3800159
Bearing, Needle, K25 x 32 x 16
20
T1180625
Gear, Output, 3rd, 38T
21
T1182212
Gear, Output, 4th, 31T
22
T1181180
Bush, 3rd/4th, Splined
2 шт. в узле
23
T1182201
Rondelle (Lock)
24
T1182202
Rondelle (Lock)
25
T1180158
Gear, 5th, Ouput
26
T1180675
Gear, 1st, Output
27
T3800151
Bearing, Needle Roller, 25 x 2
28
T3800206
Bearing, Cyl Roller, 24.2 x 47
29
T1181293
Restrictor Plate, Oil
30
T3051063
Screw, Cap/HD, M6 x 16, Enc, R
31
T1190207
Keeper Plate
32
T1181296
Gasket, Front Bevel Box
33
T3201633
Bolt, HHF, M8 x 30, Slv
10 шт. в узле
34
T3000101
Dowel, Hollow, 8 x 14
3 шт. в узле
35
T3601275
O Ring, ID Dia 8 x Dia 2.5, FK
