Главная Каталог товаров Triumph EPC 2013 Triumph ROCKET III TOURING Triumph 2013 Transmission

Transmission

Transmission

Например: T3800056

1

T3800056

Bearing, Ball, 68 x 28 x 17.95

2

T3800059

Bearing, Ball, 72 x 35 x 16.95

3

T3800058

Bearing, Ball, 56 x 22 x 15.95

4

T1180069

Retainer Plate, Bearing

5

T1180234

Shaft/Gear, Input, 1st

6

T1180232

Gear, Input, 2nd

7

T1180235

Gear, Input, 3rd/4th

8

T1180238

Gear, Input, 5th

9

T1180269

Bush, Input 5th

10

T1180288

Spring, Belleville, 40.5 x 0.6

2 шт. в узле

11

T3500003

Circlip, 32mm Shaft

3 шт. в узле

12

T1180240

Shaft, Output

13

T1180058

Gear, output, 1st

14

T3800061

Bearing, Roller, Needle

15

T1180064

Gear,Output,2nd

16

T1180268

Bush, Plain, Output, 2nd

17

T1180236

Gear, Output, 3rd

18

T1180061

Gear, output, 4th

19

T1180059

Gear, output, 5th

20

T1180444

Dog Ring, Splined

21

T1180267

Bush, Shld, Splined

2 шт. в узле

22

T1180051

Washer,Thrust, 41 OD x 1.5

23

T3500202

Circlip

3 шт. в узле

24

T1180384

Washer, Thrust, 38 x 2.5

2 шт. в узле

25

T3332704

Screw, Torx, M6 x 14

3 шт. в узле

26

T1270796

Gear, Output, 48T, Helical

27

T1270410

Spacer, Transmission Output

28

T1179999

Washer, C, Clutch

29

T1170192

Nut, Clutch, M22

30

T3800130

Bearing, Ball, 72 x 30 x 19

31

T3550751

Washer, 22.5 x 38 x 4

32

T3800301

Snap Ring, Int, 64 x 1.5

33

T1180053

Shim, Steel, 45 x 32 x 1.0

34

T1180250

hrust Washer 38mm OD x 1.5mm

36

T1180289

Shim, Steel, 50 x 40 x 0.5
