Transmission

Transmission
1
T1180155
Sleeve Assembly, Input & Outpu
2 шт. в узле
2
T3800006
Bearing, Needle, K25x32x16
2 шт. в узле
3
T1180384
Washer, Thrust, 38 x 2.5
2 шт. в узле
4
T1181020
Gear input
5
T1181060
Gear input
6
T1181061
Bush
7
T1180281
Washer, Thrust, Input
2 шт. в узле
8
T3500003
Circlip, 32mm Shaft
2 шт. в узле
9
T1181032
Gear input
10
T1181051
Gear input
11
T1180595
Input shaft and gear
12
3800002-T0301
Bearing, Ball, DG2868 GN1C3
13
T3800196
Retaining Ring, Bearing
14
Gear output
15
T1181151
Gear output
16
T3500202
Circlip
3 шт. в узле
17
T1180291
Washer thrust
3 шт. в узле
18
T1181130
Gear output
19
T1181131
Bush
20
T1181140
Gear output
21
T1181166
Gear output
22
T1181121
Gear output
23
Output shaft
24
T3800132
Bearing, 30 x 62 x 16, DGB
25
T3800300
Snap Ring, Ext, 62 x 1.7
26
T3600112
Oil seal
27
1180160-T0301
Distance Sleeve
28
T1180177
Sprocket Gearbox, 18 T
29
T1180181
Washer, Gearbox Sprocket
30
1180175-T0301
Nut, Gearbox Sprocket

Узлы для TIGER 955i 124106 > 198874 Triumph 2002 (VIN: SMTTG730)
