Главная Каталог товаров Triumph EPC 2004 Triumph SPEEDMASTER CARBS Triumph 2004 (VIN: SMTTJ913) Transmission 179829

Transmission 179829

Transmission 179829

Например: T1180042

1

T1180042

Shaft, Input & 1st Gear

2

T1180048

Shaft, Output

3

T1180031

Gear, 2nd, Input

4

T1180032

Gear, 3rd & 4th, Input

5

T1180033

Gear, Top, Input

6

T1180034

Bush, Splined, Top, Input

7

T1180045

Gear Assy, 1st Output

8

T1180047

Gear Assy, 2nd, Output

9

T1180037

Gear, 3rd, Output

10

T1180038

Bush, Splined, 3rd/4th, Output

11

T1180039

Gear, 4th, Output

12

T1180043

Spacer, Dogged, Output

13

T1180041

Gear, Top, Output

14

T3800006

Bearing, Needle, K25x32x16

2 шт. в узле

15

T1180156

Sleeve Assy, Needle bearing

2 шт. в узле

16

3800002-T0301

Bearing, Ball, DG2868 GN1C3

17

T3800196

Retaining Ring, Bearing

18

T3800132

Bearing, 30 x 62 x 16, DGB

19

T3800300

Snap Ring, Ext, 62 x 1.7

20

T1181188

Distance Sleeve

21

1180175-T0301

Nut, Gearbox Sprocket

22

T1180181

Washer, Gearbox Sprocket

23

T1182000

Sprocket, Gearbox (18T)

24

T3600068

Seal, Oil, 40 62 6, Clockwise

25

T1180281

Washer, Thrust, Input

2 шт. в узле

26

T1180049

Washer, Thrust, 41 OD x 1

3 шт. в узле

27

T3500003

Circlip, 32mm Shaft

2 шт. в узле

28

T3500202

Circlip

3 шт. в узле

29

T3555005

Washer, 25.5 x 38 x 1.5

2 шт. в узле

30

T3500201

Circlip, EXT, 23.5 x 1.2

2 шт. в узле
