TIMING BELT » UNCLASSIFIED

TIMING BELT » UNCLASSIFIED
Например: 24510041BB
1
24510041BB
VERTICAL BELT OUTER COVER
2
24510031BB
CENTRAL EXTERNAL COVER
3
24510051BB
HORIZONTAL BELT EXTERNAL COVER
4
24510012AB
VERTICAL BELT INTERNAL COVER
5
24510022AB
HORIZONTAL BELT INTERNAL COVER
6
85310021A
pc - Rondelle (spring)
7
77150658B
Vis
8
77110518B
pc - Vis
9
77110471A
pc - Vis
10
14710142A
LAYSHAFT TIMING
11
88210031A
5 pc - .SNAP RING
12
68010131A
pc - KEY, WOODRUFF 4X5X10
13
17120202B
TIMING GEARS SET
14
85110131A
pc - Rondelle (Lock)
15
75011601A
.NUT M14X1X7
16
68010131A
pc - KEY, WOODRUFF 4X5X10
17
71311661A
Entretoise
18
25510041A
PULLEY, TIMING
19
85610022A
.BELT ROLLER SEPARATING WASHER
20
85211731A
0 pc - Rondelle
21
70350062A
ELASTIC-STOP RING NUT
22
73710091B
2 pc - Timing drive toothed belt (Z=95)
23
45110042A
STRETCHING PIN
24
70250222A
.BEARING
25
45110081A
BUSHING
26
735033450
Seeger
27
735002054
.SPRING RING
28
45110331A
ECCENTRIC TENSIONER
29
45110012A
MOVABLE TENSIONER ROLLER PIN
30
74940081A
2 pc - Nut
31
45110341A
PULLEY, MOVABLE TENSIONER
